CDX-M620/M670
4-18. PRINTED WIRING BOARD — DISPLAY SECTION —
(IC60)
B-9
(IC61)
B-11
(IC62)
A-13
LED60
A-1
LED62
A-2
LED63
A-12
LED64
B-2
LED65
B-12
(D61)
A-11
(D62)
A-2
(D63)
A-2
(D64)
A-3
(D65)
A-3
(D66)
A-3
(D67)
B-10
(D68)
A-12
(D70)
A-13
• Semiconductor Location
Ref. No.
Location
Ref. No.
Location
Ref. No.
Location
LED66
B-2
LED67
B-12
LED68
C-2
LED69
C-12
(Q60)
A-2
(Q61)
A-2
(Q62)
B-2
(
) : SIDE B
(Page 50)
