Rear panel – SMC Networks SMC-EZ1024DT User Manual
Page 15
R
EAR
P
ANEL
3
Rear Panel
The AC power socket is located on the rear panel of the switch.
FDX
On
The port is in full-duplex mode.
Off
The port is in half-duplex mode.
Flashing
Packet collision is occurring in half-duplex
mode.
Port and Switch Status LEDs
LED
Condition
Status
100-240VAC 50-60Hz 1A
100-240 VAC, 50-60 Hz, 1A
