7. adjustments and settings – Samsung SRP-350 User Manual

Page 6

5. Be sure to note the correct direction that the paper comes off the roll.

6. Pull out a small amount of paper, as shown. Then close the cover.

7. Tear off the paper as shown.

Notes : When closing the cover, press the center of printer cover firmly to prevent

paper miss-loading

1-7. Adjustments and Settings

The SRP-350 is set up at the factory to be appropriate for almost all

users. It does, however, offer some settings for users with special

requirements.

It has DIP switches that allow you to change communication settings,

such as handshaking and parity check, as well as print density.

The SRP-350 also has a near-end sensor for the paper. This can give

you a warning when the paper is almost out. If you find that there is

not enough paper remaining on the roll when the near-end sensor is

triggered, you can change the near-end sensor setting. Rotate the

near end sensor tab at front or rear position.(See the below figure)
