26
Control codes
Hexadecimal
codes
Function
c 3 n 1B 63 33 n Select paper sensor to output paper end
signals
c 4 n 1B 63 34 n Select paper sensor to stop printing
c 5 n 1B 63 35 n Enable/Disable panel button
d n 1B 64 n Print and feed n lines
p m t1 t2 1B 70 m t1 t2 Generate pulse
t n 1B 74 n Select character code table
{ n 1B 7B n Turn on/off upside-down printing mode
p n m 1C 70 n m Print NT bit image
q n …. 1C 71 n … Define NV bit image
! n 1D 21 n Select character size
$ nL nH 1D 24 nL nH Set absolute vertical print position in
page mode
* x y ….. 1D 2A x y ….. Define downloaded bit image
/ m 1D 2F n Print downloaded bit image
: 1D 3A Start/end macro definition
B n 1D 42 n Turn white/black reverse printing mode
on/off
H n 1D 48 n Select printing position of HRI characters
I n 1D 49 n Transmit printer ID
L nL nH 1D 4C nL nH Set left margin
P x y 1D 50 x y Set horizontal and vertical motion units
V m
V m n
1D 56 m
1D 56 m n
Select cut mode and cut paper
W nL hH 1D 57 nL nH Set printing area width
₩ nL nH 1D 5C nL nH Set relative vertical print position in page
mode
^ r t m 1D 5E r t m Execute macro
a n 1D 61 n Enable/Disable Automatic status back
f n 1D 62 n Select font for HRI characters
h n 1D 68 n Set bar code height
k m ….NUL
k m n …
1D 6B m… NUL
1D 6B m n …
Print bar code
r n 1D 72 n Transmit status
v 0 m …. 1D 76 30 Print raster bit image
w n 1D 77 n Set bar code width
27
Command Notation
[Name]
[Format]
[Range]
[Description]
The name of the command.
The code sequence. ASCII Indicates the ASCII equivalents.
Hex indicates the hexadecimal equivalents.
Decimal indicates the decimal equivalents.
[ ] k indicates the contents of the [ ] should be repeated k times.
Gives the allowable ranges for the arguments.
Describes the function of the command.
Explanation of Terms
LSB Least Significant Bit
HT
[Name]
[Format]
[Description] Horizontal tab.
ASCII HT
Hex 09
Decimal 9
Moves the print position to the next horizontal tab position.
LF
[Name]
[Format]
[Description] Print and line feed.
ASCII LF
Hex 0A
Decimal 10
Prints the data in the print buffer and feeds one line based on the current
line spacing.
FF
[Name]
[Format]
[Description] Print and return to standard mode in page mode.
ASCII FF
Hex 0C
Decimal 12
Prints the data in the print buffer collectively and returns to standard mode.
CR
[Name]
[Format]
[Description] Print and carriage return.
ASCII CR
Hex 0D
Decimal 13
When automatic line feed is enabled, this command functions the same as
LF : when automatic line feed is disabled, this command is ignored.
