56
Section 8
REPLACEMENT DECALS AND INFORMATION PLATES
1 2
5
8
6
4
9
12
7
ROTATING BLADES AND BELTS
WARNING
KEEP HANDS, FEET & CLOTHING CLEAR
KEEP ALL GUARDS IN PLACE
SHUT OFF ENGINE & DISENGAGE BLADE
CLUTCH BEFORE SERVICING
CLEAR AREA OF DEBRIS BEFORE MOWING
USE CAUTION IN DIRECTING DISCHARGE
KEEP BYSTANDERS, CHILDREN & PETS AWAY
READ INSTRUCTION MANUAL BEFORE OPERATING
DO NOT OPERATE WITHOUT DISCHARGE CHUTE, MULCHING
KIT, OR ENTIRE GRASS CATCHER INSTALLED 481040
DANGER
SPINNING BLADE
KEEP CLEAR
CONTACT CAN INJURE
48071
48404
STC 2K RDP1
WARNING
INSTALL BELT COVER BEFORE
OPERATING MACHINE
READ OPERATOR'S MANUAL
481039
CUTTING
HEIGHT
5.5
5
4.5
4
3.5
3
2.5
2
1.5
1
482101
482100
FORWARD
REVERSE
F
R
Heavy-Duty
Commercial
481971
MANUFACTURED UNDER ONE OR MORE
OF THE FOLLOWING PATENTS:
4, 487, 006 4, 991, 382 5, 832, 708
4, 885, 903 4, 998, 948 5, 865, 018
4, 920, 733 5, 118, 617
4, 967, 543 5, 826, 416
PATENTS PENDING
10
482214
PULL OUT TO ENGAGE
ON
START
PUSH IN TO DISENGAGE
OFF
MOWER DECK
CHOKE
SLOW
FAST
R
482213
FUEL VALVE
OFF
RH
FUEL TANK
LH
FUEL TANK
11
13
482216
CUB
3
