Page 32

Section 7

Figure 7-7 Kawasaki Fuel Filter Location

To avoid injury from burns, allow the mower to cool
before removing the fuel tank cap and refueling.

1. Close the shutoff valve (located on the left side for the

KA model, right side for the KH model). Remove the

two clamps securing the fuel filter to the fuel hose.

Remove the fuel filter, noting the proper direction.

2. Install a new fuel filter. Be sure it is installed in the

proper direction. Secure to the fuel hose using the two

clamps.

7.6 ENGINE AIR CLEANER

A. Cleaning and/or Replacing Air Cleaner
Element

For any air cleaner, the operating environment dictates

the air cleaner service periods. Inspect and clean the

air cleaner element after every 100 hours of operation or

bi-weekly, whichever occurs first and replace the

element if required.

-NOTE-

In extremely dusty conditions it may be necessary

to check the element once or twice daily to

prevent engine damage.

1. For the KH model, remove the wing nut securing the

air cleaner cover to the engine. For the KA model,

remove the two clips securing the air cleaner cover

to the engine. Remove the air cleaner cover and set

aside.

2 Remove the air cleaner and inspect.

3. Clean or replace the air cleaner and foam pre-

cleaner as recommended by the engine

manufacturer.

STC99EFF

FUEL FILTER

STC99KFF

Figure 7-8 Kohler Fuel Filter Location
