53
Section 8
1 48023 Hourmeter
2 48298 Fuse, 20 amp
3 48017-02 Key, Ignition
4 48017-04 Nut, Hex 5/8-32
5 48017-03 Lockwasher, 5/8” Internal
6 461073 Electric PTO Clutch
7 48798 Switch, Ignition
8 481687 Switch, PTO
9 48788 Relay
10 04031-01 Lock Washer, #10 External Tooth
11 04020-01 Nut, Hex #10-32
12 481637 Switch, N/O
13 423218 Panel, Instrument
14 482210 Choke Control - Kawasaki
482221 Choke Control - Kohler
15 482209 Throttle Control
16 481638 Switch, Seat
17 482313 Module, Interlock
18 04010-01 Screw, #10-32 x .5” Phillips Head
19 48015 Battery
20 04001-44 Bolt, Hex Head 1/4-20 x .5”
21 04020-02 Nut, Hex 1/4-20
22 48029-14 Cable, Battery Black (negative)
23 48029-13 Cable, Battery Red (positive) - Kawasaki
48029-02 Cable, Battery Red (positive) - Kohler
24 482215 Wiring Harness, Main
25 48030-10 Clamp, Cable 3/4” ID
26 48030-09 Clamp, Cable 1/2” ID
27 42413 Block, Fuse
28 04010-11 Screw, #10-32 x 1.5” Phillips Head
29 482093 Adaptor, Wiring Harness (Kawasaki only)
30 04063-24 Key, 1/4 x 1/4 x 2-3/4”
31 04041-28 Flatwasher, 7/16-.469 x 1-3/4” x 1/4”
32 04030-05 Lockwasher, 7/16”
33 04001-101 Bolt, Hex Head 7/16-20 x 2-1/2” UNF
Ref. Part
No. No. Description
ELECTRICAL SYSTEM (KAWASAKI & KOHLER)
