55
Section 8
1 HG 2510065 Housing Kit (Includes Housing, Journal Bearing)
2 HG 2510066 End Cap
3 HG 50641 Straight Headless Pin
4 HG 51055 Hex Head Screw 5/16-18 x 1.0
5 HG 50381 End Cap O-Ring
6 HG 2513027 Charge Pump Kit (Includes Charge Cover, Gerotor Assy., O-Ring)
7 HG 50273 Gerotor Assembly
8 HG 9004100-1430 O-Ring, Charge Pump Cover
9 HG 2510011 Charge Relief Valve Kit
10 HG 50633 Socket Head Screw
11 HG 2510027 Check Valve Kit (Includes Check Plug, Spring, O-Ring, Orifice Check Valve)
12 HG 2513030 Bypass Valve Kit (Includes Bypass Valve, O-Ring, Back-up Ring)
13 HG 9006110-0120 Backup Ring
14 HG 70331 Cylinder Block Kit
15 HG 2003014 Block Spring
16 HG 2003017 Block Thrust Washer
17 HG 2003044 Roller Thrust Bearing
18 HG 2003087 Swash Plate
19 HG 2003005 Trunnion Arm
20 HG 2000015 Guide Slot
21 HG 2003023 Cradle Bearing
22 HG 9008000-0126 Lip Seal
23 HG 2003020 Pump Shaft
24 HG 2003043 Ball Bearing
25 HG 2003016 Retaining Ring
26 HG 9008000-0128 Lip Seal
27 HG 2003052 Retaining Ring
28 HG 2003018 Spacer
29 HG 2513038 Shaft Kit (Includes Pump Shaft, Ball Bearing, Retaining Ring)
30 HG 2513018 Overhaul Seal Kit (Includes Gasket, Trunnion Seal, Input Shaft Seal, Charge Pump O-Ring)
Ref. Part
No. No. Description
HYDRAULIC PUMP ASSEMBLY
* Common hardware which should be purchased locally. All bolts Grade 5 plated, all other fasteners zinc plated.
