Page 21
21
System Configurations and Speaker Connections
SYSTEM TYPE 4
For a speaker system consisting of high-impedance ceiling
speakers (70V LINE).
Audio from the AV components (monaural) and the
microphones is output from the ceiling speakers.
• Input/output
• Delay
Distance compensation is not set.
SYSTEM TYPE 5
For a speaker system consisting of low-impedance ceiling
speakers (Lo. imp).
Audio from the AV components (monaural) and the
microphones is output from the ceiling speakers.
Adjust the SPEAKER OUT controls so that the output
level from the SPEAKERS CH-1/2 terminals and from the
SPEAKERS CH-3/4 terminals is equal to each other.
• Input/output
• Delay
Distance compensation is not set.
SYSTEM TYPE 6 to 9
For a speaker system consisting of a pair of front speakers
and low-impedance satellite speakers (Lo. imp).
Audio from both the AV components and the microphones
is output from all speakers.
• Input/output
SPEAKERS
LINE OUT
SP 1
SP 2
70V
LINE
(SP 3-4)
CH-1
CH-2
CH-3
CH-4
MIC IN
ON/OFF
-
-
ON
ON
ON
ON
ON
LEVEL
-
-
0dB
0dB
0dB
0dB
0dB
LINE IN
L
ON/OFF
-
-
ON
ON
OFF
OFF
OFF
LEVEL
-
-
-3dB
0dB
0dB
0dB
0dB
LINE IN
R
ON/OFF
-
-
ON
OFF
ON
OFF
OFF
LEVEL
-
-
-3dB
0dB
0dB
0dB
0dB
AV/RGB
IN L
ON/OFF
-
-
ON
ON
OFF
ON
OFF
LEVEL
-
-
-3dB
0dB
0dB
0dB
0dB
AV/RGB
IN R
ON/OFF
-
-
ON
OFF
ON
OFF
ON
LEVEL
-
-
-3dB
0dB
0dB
0dB
0dB
SPEAKERS
LINE OUT
SP 1
SP 2
SP 3
SP 4
CH-1 CH-2 CH-3 CH-4
MIC IN
ON/OFF ON
ON
ON
ON
ON
ON
ON
ON
LEVEL
0dB
0dB
0dB
0dB
0dB
0dB
0dB
0dB
LINE IN
L
ON/OFF ON
ON
ON
ON
ON
OFF
OFF
OFF
LEVEL
-3dB
-3dB
-3dB
-3dB
0dB
0dB
0dB
0dB
LINE IN
R
ON/OFF ON
ON
ON
ON
OFF
ON
OFF
OFF
LEVEL
-3dB
-3dB
-3dB
-3dB
0dB
0dB
0dB
0dB
AV/RGB
IN L
ON/OFF ON
ON
ON
ON
ON
OFF
ON
OFF
LEVEL
-3dB
-3dB
-3dB
-3dB
0dB
0dB
0dB
0dB
AV/RGB
IN R
ON/OFF ON
ON
ON
ON
OFF
ON
OFF
ON
LEVEL
-3dB
-3dB
-3dB
-3dB
0dB
0dB
0dB
0dB
SPEAKERS
LINE OUT
SP 1
SP 2
SP 3
SP 4
CH-1 CH-2 CH-3 CH-4
MIC IN
ON/OFF ON
ON
ON
ON
ON
ON
ON
ON
LEVEL
0dB
0dB
0dB
0dB
0dB
0dB
0dB
0dB
LINE IN
L
ON/OFF ON
OFF
ON
OFF
ON
OFF
OFF
OFF
LEVEL
0dB
0dB
0dB
0dB
0dB
0dB
0dB
0dB
LINE IN
R
ON/OFF OFF
ON
OFF
ON
OFF
ON
OFF
OFF
LEVEL
0dB
0dB
0dB
0dB
0dB
0dB
0dB
0dB
AV/RGB
IN L
ON/OFF ON
OFF
ON
OFF
ON
OFF
ON
OFF
LEVEL
0dB
0dB
0dB
0dB
0dB
0dB
0dB
0dB
AV/RGB
IN R
ON/OFF OFF
ON
OFF
ON
OFF
ON
OFF
ON
LEVEL
0dB
0dB
0dB
0dB
0dB
0dB
0dB
0dB
