Repair Parts (cont’d)
Now that you have purchased this Water Heater, should a need ever exist for repair parts or service, simply contact the com-
pany it was purchased from or the manufacturer listed on the model rating plate on the water heater.
Be sure to provide all pertinent facts when you call or visit.
Selling prices will be furnished on request or parts will be shipped at prevailing price and you will be billed accordingly.
The model number of your Gas Water Heater will be found on the model rating plate located above the gas control valve.
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION:
MODEL NUMBER
(TYPE GAS) NATURAL OR PROPANE (L.P.)
SERIAL NUMBER
PART DESCRIPTION
PART NUMBER
THIS IS A REPAIR PARTS LIST, NOT A PACKING LIST.
37
KEY PART
NO. DESCRIPTION
PART NUMBER
1.
Vent Cap w/Screen
9001957
2.
Adaptor, Flue Mounting
9002728
3.
5
′ ABS Schedule 40 Vent Pipe
9002106
4.
90° ABS Schedule 40 Elbow
9002107
5.
Vent/Blower Adapter
9002506
6.
Blower
9002669
7.
Flue Adaptor Gasket
9002567
(6
″ x 10.102″)
8.
Blower Gasket
9002508
9.
Venting; Manual Reset Switch
9002678
10. Vent Hood Assembly
9002670
11. Rubber Gasket – Wiring
9002519
12. T&P Valve
9000728
13. Dip Tube
9002365
14. Anode Rod
9000734
15. Wiring
Harness
9002520
16. Drain Pan
9001608
17. Hot Surface Ignition Assembly
9002518
18. Orifice (Natural) Standard
0230279 (#25)
18. Orifice (L.P.) Standard
0230260 (#43)
18. Orifice (Nat.) High Altitude
0230142 (#28)
18. Orifice (L.P.) High Altitude
0230261 (#44)
* Consists of the following parts:
Flue Adaptor
9001290
Adaptor Gasket
9001292
Adaptor Plate w/Gasket
9001294
KEY PART
NO. DESCRIPTION
PART NUMBER
19. Burner Assembly (Nat.)
9003040
19. Burner Assembly (L.P.)
9003048
20. Inner Door
9000281
21. Drain Valve (Brass)
9000469
22. Manifold (Natural)
9002654
22. Manifold
(L.P.)
9002655
23. Right Access Door w/Gasket
9000695
24. Left Access Door w/Gasket
9000696
25A. Access Door Clips (2)
9000694
25B. Jacket/Access Door Clips (8)
9001305
26. Pressure Switch (Air) Cover
9002569
27. Gas Thermostat (Nat.)
9002745
27. Gas Thermostat (L.P.)
9002746
28. Power Cord
9003095
29. Mounting Bracket
9002512
30. On/Off Switch
9001773
31. Pressure Switch (Air)
9002568
32. Flue Baffle Assembly
9002653
33. Baffle Adaptor Collar Assembly
*
34. Optional (Deluxe)
9002749
Horizontal Vent Kit
MODEL: 75-70
