FINISHER (AR-FN5 N)
105
6
OP
T
IO
N
AL E
Q
UIP
M
E
N
T
3 Use the and keys to select "STAPLE SORT" and press the OK key.
● Also the OUTPUT key can be used to select an output mode.
4 Set the number of copies and press the START ( ) key.
● When copying of a set is completed, the copies will be automatically stapled and
delivered to the offset tray.
Using the platen glass
1 Set an original face down on the platen glass with the corner to be
stapled to the upper right position.
● If the number of copies in one set is more than 30, the copies will not be stapled.
● If the orientation of the original does not match that of the copy paper, the image of the
original will be rotated. The stapling position varies with the orientation of the original.
● When copying 8-1/2" x 14" or 11" x 17" size originals with portrait orientation images,
copies will be stapled at the position shown below.
Stapling position
Stapling position
