43
Basic Operations of the Function Menu
Chapt
er
3
Pre
par
at
ion
s
a) This is displayed only when TCG on page P5 TC of the function menu is
set to “INT”, and PRST/RGN is set to “PRESET”.
P1 VIDEO page
P2 AUDIO page
F4: CNTR SEL
Selects the type of time data to display in
the time data display area.
TC: Timecode
COUNTER: Elapsed recording or
playback time
UB: User bits
F5: TCG SET
• When CNTR SEL is set to “TC” ,
displays a screen where you can set
the initial value of the timecode
generated by the internal timecode
generator
a)
• When CNTR SEL is set to “UB” ,
displays a screen where you can set
timecode user bits
a)
F6:
(Unassigned function button)
Item
Setting
F1: V INPUT
Selects the video input signal.
HDSDI: HDSDI signal
SDSDI: SDSDI signal
i.LINK: i.LINK signal (when the
separately sold PDBK-201 option
board is installed)
SG: Test signal from internal signal
generator (Normally this item is not
displayed. It appears when you hold
the button down for 3 seconds.)
F2: VID. PROC
Selects the method used to control the
internal video signal processor and make
related settings.
LOCAL: Use the function menu to
change settings.
MENU: Use the setup menu to change
settings.
F3: VIDEO
Sets the output level for HD/SD video
signals (range –
∞ to +3 dB).
PRESET: Set the video signal output
level to a preset value, regardless of
manual setting.
Manual setting: While the setting value
is flashing, turn the PUSH
SET(S.SEL) knob to adjust the video
signal output level.
F4: CHROMA
Sets the output level for HD/SD chroma
signals (range –
∞ to +3 dB).
PRESET: Set the chroma signal output
level to a preset value, regardless of
manual setting.
Manual setting: While the setting value
is flashing, turn the PUSH
SET(S.SEL) knob to adjust the
chroma SETUP signal output level.
Item
Setting
F5: HUE/CHRM
PHS
Sets the hue (chroma phase).
PRESET: Set the hue (chroma phase) to
a preset value, regardless of manual
setting.
Manual setting: While the setting value
is flashing, turn the PUSH
SET(S.SEL) knob to adjust the hue
(chroma phase) over the range
±30°.
F6: SETUP/
BLACK
Sets the HD/SD output black setup level
or black level.
PRESET: Set the level to the preset
value, regardless of the manual
setting.
Manual setting: While the setting value
is flashing, turn the PUSH
SET(S.SEL) knob to set the black
setup level (in 59.94i/59.94P/29.97P
mode) over the range ±30 IRE or the
black level (in 50i/50P/25P mode)
over the range ±210 mV.
Item
Setting
F1: A1 INPUT
Selects the audio input signal to assign
to audio channel 1.
SDI: Audio signal embedded into SDI
signal
ANALOG1: Analog 1 audio signal
AES/EBU1: Signal input to the DIGITAL
AUDIO(AES/EBU) IN 1/2 connectors
SG: Test signal from internal signal
generator (Normally this item is not
displayed. It appears when you hold
the button down for 3 seconds. The
test signal is assigned to audio
channels 1 to 8 simultaneously.)
Press one of the function buttons
corresponding to A1 INPUT to A8
INPUT again to stop output of the
test signal.
i.LINK: i.LINK signal (when the
separately sold PDBK-201 option
board is installed)
F2: A2 INPUT
Selects the audio input signal to assign
to audio channel 2.
SDI: Audio signal embedded into SDI
signal
ANALOG2: Analog 2 audio signal
AES/EBU2: Signal input to the DIGITAL
AUDIO(AES/EBU) IN 1/2 connectors
F3: MONITR L
Selects the channel to monitor as the left
monitor channel.
CH1, CH2, CH3, CH4, CH5, CH6, CH7,
CH8
CH1/2, CH3/4, CH5/6, CH7/8 (MIX)
F4: MONITR R
Selects the channel to monitor as the
right monitor channel.
CH1, CH2, CH3, CH4, CH5, CH6, CH7,
CH8
CH1/2, CH3/4, CH5/6, CH7/8 (MIX)
Item
Setting
