8
SK 100 G2 bodypack transmitter
³ ቢ
·
»
¿
´
µ
¸
¶
º
²
·
ብ ቦ ቧ ቨ ቩ
¹
¾
ባ ቤ
Operating controls LC display panel
³
Microphone/line input (MIC/LINE),
3.5 mm jack socket
· Antenna
»
Red LED for operation and
battery status indication (ON/LOW BAT)
¿
Yellow LED for audio peak (AF PEAK)
´ SET
button
² ̄
/
̆ rocker button (DOWN/UP)
¶
Battery compartment
º Battery compartment cover
¾
Unlocking button
µ ON
/ OFF button
(serves as the ESC (cancel) key in the
operating menu)
¸
LC display
¹ MUTE
switch
ቢ
Alphanumeric display
ባ
“B.CH“ – appears when the channel bank and the
channel number are displayed
ቤ
“MHz“ – appears when the frequency is displayed
ብ 4-step battery status display
ቦ
Lock mode icon
(lock mode is activated)
ቧ
“PILOT” display
(pilot tone transmission is activated)
ቨ
“MUTE” display
(audio input is muted)
ቩ
7-step level display for audio signal “AF”
