page 6
NAME & FUNCTION OF EACH PART, SIDE VIEW
V ideo In (yellow )
Audio In (w hite)
A V In
V ideo Out (yellow )
A udio O ut (white)
A V Out
15) AV/IN: Audio/Video Input
Audio/Video IN: 3.5 mm jack for audio/video line in.
16) AV OUT: Audio/Video Output
Audio/Video OUT: 3.5 mm jack for audio/video line out
17) POWER: AC/Battery Power Switch
18) AC 5V IN: 5V/1A Power Input
19) SD Card Slot
20) Battery Compartment Cover
SIDE VIEW
