MENU SETUP CONTINUED
(5)
Video Detection Block Sensitivity Setup:
Changing the alert value setup may effect the recording sensitivity of the
Motion Detection.
Sensitivity Bar: Colour black indicates
image variable value & colour red
indicates the MD threshold.
MD Energy: Current image variation
value.
MD Threshold: Press / buttons, to
change the motion detection
threshold value.
MANUAL RECORD & SCHEDULE RECORD
Selectable manual or schedule recording, basic setups are shown below:
1. MANUAL RECORD: Press REC button to start recording.
(1)
Video Size/Frame Rate:
NTSC
352x240
704x240
704x480
FRAME RATE (MAX)
30 fps
24 fps
12 fps
PAL
352x280
704x280
704x560
FRAME RATE (MAX)
25 fps
20 fps
10 fps
(2)
Image Quality:
HIGH QUALITY
HQ
Using high recording quality (more SD card
storage capacity will be required)
MEDIUM QUALITY MQ
Using medium recording quality
LOW QUALITY
LQ
Using low recording quality (less SD card
storage capacity will be required)
(3)
Audio Record: Enable or disable audio recording.
M D
S E N S
I
T I
V
I
T Y
