Handles & Controls
Footnotes:
TP 400-5137-7-WB-N
Manual No. 7006059 21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
7
Part No Description Item Qty Note
20A 7051698 ASSEMBLY, Transfer Rod European models
21 7010937 CLIP, Transfer Rod Self-Propelled Models
22 7090895 TEE-NUT, 5/16-18 Self-Propelled Models
23 7012114 BUSHING, Differential Self-Propelled Models
24 7090595 BOLT, 5/16-18 x 3/4" Flange Lock, Grade 5
25 7090238 SCREW, 5/16-24 x 1" Hex Cap, Grade 5
26 7090799 BOLT, 5/16-18 x 5/8" Carriage, Grade 5 Was 91026 (Used on All Models)
27 7091601 NUT, 5/16-18 Hex Flange Lock, Grade 5 Was 91070 (Used on All Models)
28 7091606 NUT, 5/16-24 Center Lock, Grade 5 Was 91074 (Used on All Models)
28 7091606 NUT, 5/16-24 Center Lock, Grade 5 Was 91074 (Used on All Models)
29 7023813 CLIP, Cable/Wiring
30 7091740 4 SCREW, 5/16-18 x 1-7/8 Curved Head, Grade 2 Was 91189 (Used on All Models)
31 7035744 T-KNOB, 5/16-18
32 7079577 SCREW, 1/4-20 x 1-1/2 Hex Cap, Grade 5
33 7090053 WASHER, 1/4 Internal Tooth Lock Was 91023 (Used on All Models)
34 7091576 NUT, 1/4-20 Hex, Grade 5 or B Was 91100 (Used on All Models)
35 7090505 SCREW, 1/4-20 x 2" Hex Cap, Grade 5
36 7014343 4 BUSHING
37 7023792 PIN, 1/4" X 1-1/2"
38 7091020 PUSH-NUT, 1/4"
39 7024211 DECAL, Blade Control (L.H. Side) Used on All (Except European)
7029782 DECAL, Operator's Presence Control Used on European Models
7029785 DECAL, Handle International Warning Used on European Models
40 7026141 GUIDE, Rope
41 7075634 GRIP, Foam Was 73115, Note #1
7022460 GRIP, Foam Used on P216012E &
P216512BV
42 7024087 DECAL, Speed Select Except European
7029783 DECAL, Speed Select European Models
43 7023153 CLAMP, Casing
44 7090391 WASHER, 5/16 Internal Tooth Lock
45 7090545 SCREW, 5/16-24 x 1-1/2" Machine, Grade 5
46 7022779 GUIDE, Rope Used on Grass Bag Models
47 7029217 ASSEMBLY, Speed Control Lever (Includes Items 48 thru 51),
Note #1
47A 7029233 ASSEMBLY, Speed Control Lever Includes Items 48A, 49A, 50A &
51
48 7029217 ROD, Upper Was 29153, Note #1
48A 7029189 ROD, Upper NRP215012, RP215012
49 7029217 ROD, Intermediate Was 29154, Note #1
49A 7029190 ROD, Intermediate NRP215012, RP215012
Note 1: RP215012T2, RP216012, NP216012, EP216012, P216012, P216012E, P216012TV, P216512BV, FRP216012TV,
EFRP216012TV, FRP216012, FRP216016, EFRP216512TV, EFRP216516TV & EFRP216516BV.
Note 2: N215012, 215012, 216015, NR215012, 8215012.
