Electric Start
Footnotes:
TP 400-5137-7-WB-N
Manual No.
7006059
21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
49
Part No
Description
Item
Qty
Note
7067012
KIT, Battery
(Includes Items 1 Thru 4)
1
7067012
BATTERY, 12 Volt, 35 CCA
Was 19763
2
7015488
HARNESS, Battery
3
7043977
2
SCREW, #10-24 x 1/2" Hex Head Cap
4
7090932
2
NUT, #10-24 Square
7058120
ASSEMBLY, Switch/Brkt.
(Incl. Items 5 Thru 10)
5
7011138
KEY, (Set of Two)
6
7023506
ASSEMBLY, Seal & Face Nut
7
7071972
BRACKET, Ignition Switch
8
7029080
COVER, Switch
9
7012685
NUT, 3/4-20 Hex Lock
10
7028765
SWITCH, Ignition-(spring loaded ON/OFF 2 prong)
11
7016132
SPACER
12
7090053
2
WASHER, 1/4 Internal Tooth Lock
Was 91023
13
7090095
2
NUT, 1/4-28 Hex Grade 5 or B
Was 91024
14
7029081
HARNESS, Wiring
15
7032906
BRACKET, Battery
16
7036132
COVER, Battery
17
7090731
2
BOLT, 5/16-18 x 1/2" Short Neck. Carr., Gr. 5
18
7091601
3
NUT, 5/16-18 Hex Flange Lock Grade 5
Was 90585
19
7012652
CLIP, Wiring
20
7061188
CHARGER, Battery (120 Volt - 60 Hertz)
Was 18834
7018977
CHARGER, Battery (230 Volt - 50 Hertz)
21
7090799
BOLT, 5/16-18 x 5/8" Short Neck. Carriage, Gr. 5
Was 91026
22
7011791
RETAINER, 5/16 Bolt
23
7091025
2
SCREW, 1/4-28 x 1-3/8" Hex Hd. Cap, Gr. 5
