Page 13
Cutting Deck, Blades
Footnotes:
TP 400-5137-7-WB-N
Manual No.
7006059
21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
13
Part No
Description
Item
Qty
Note
32
7090316
2
BOLT, 5/16-18 x 3/4" Carriage, Grade 5
33
7090189
2
WASHER, 5/16 Internal/External Lock
34
7024085
2
WINGNUT, 5/16-18 Nylok
35
7091076
WASHER, 5/16 Flat
36
7029000
3/16" THICK SPACER, Blade Hub
("FRP" & "EFRP" Models)
7044770
1/16" THICK SPACER, Blade Hub
37
7046446
BAFFLE, Belt
38
7046471
PLUG, 5/16" Square Hole
(Qty. 3 on Push)
39
7045264
PLUG, 5/16" Round Hole
(Qty. 3 on Push; Qty. 2 on Self-
Propelled)
40
7091122
4
SCREW, 1/4-20 X 1/2" Hex Self-Tapping
Was 90539
41
7046720
DECAL, Warning Chute/Deflector
42
7046780
2
PLUG, Hole
43
7072426
BAFFLE, Front
(FRP216016, EFRP216516TV
and EFRP216516BV Models
Only)
44
7090951
2
NUT, 5/16-18 Hex Center Lock
