Handles & Controls
Footnotes:
TP 400-5137-7-WB-N
Manual No. 7006059 21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
5
Part No Description Item Qty Note
1 7046914 HANDLE, Upper Was 24889
7035252 HANDLE, Upper NRP215012, RP215012
7074384 HANDLE, Upper Was 33473, Note #2
7074254 HANDLE, Upper 215015, 216015, 216515BV
7046914 HANDLE, Upper Used on P216012E
2 7024890 HANDLE, Middle Note #1
7036350 HANDLE, Middle Note #3
3 7033985 HANDLE, Lower Left Hand Note #1
7046502 HANDLE, Lower Left Hand Was 35343, Note #3
7046502 HANDLE, Lower Left Hand 215015, 216015, 216515BV
4 7033986 HANDLE, Lower Right Hand Note #1
7035342 HANDLE, Lower Right Hand Note #4
5 7017072 CONTROL, Blade Note #3
7047011 CONTROL, Blade 215015, 216015, 216515BV
6 7033904 CLIP, Blade Control Used on All Except 215015
7034872 CLIP, Blade Control 215015, 216015, 216515BV
7 7025036 CABLE, Blade Control (50-1/2" Long) Note #1
7026136 CABLE, Blade Control (74-1/16" Long) Used on RP215012T2
7035808 CABLE, Blade Control (46-1/16" Long) Note #3
7035840 CABLE, Blade Control (60" Long) P216012TV, FRP216012TV,
EFRP216012TV
7072933 CABLE, Blade Control (49-1/4" Long) 215015, 216015, 216515BV
8 7032826 HANDLE, Wheel Drive Self-Propelled Models
9 7014307 GRIP, Wheel Drive Handle Self-Propelled Models
7029775 GRIP, Wheel Drive Handle European Models
10 7025013 CABLE, Clutch Pull (Z-BEND) (41-7/16" Long) Note #1
7023134 CABLE, Clutch Pull (Z-BEND) (36-1/16" Long) NRP215012, RP215012
11 7012121 COVER, Vinyl Self-Propelled Models
12 7012122 SPRING, Clutch Self-Propelled Models
13 7038478 SECTOR, Speed Self-Propelled Models
14 7024641 TIE, Wire (3) Self-Propelled Models
15 7012093 SPRING, Speed Control Self-Propelled Models
16 7090188 WASHER, 3/8" Flat Self-Propelled Models
17 7023801 GRIP, Speed Control Handle Note #1
7023801 GRIP, Speed Control Handle NRP215012, RP215012
18 7034892 ANCHOR, Speed Control Self-Propelled Models
19 7032408 GUIDE, Lower V-Belt Self-Propelled Models
20 7023790 ROD, Transfer American models
Note 1: RP215012T2, RP216012, NP216012, EP216012, P216012, P216012E, P216012TV, P216512BV, FRP216012TV,
EFRP216012TV, FRP216012, FRP216016, EFRP216512TV, EFRP216516TV & EFRP216516BV.
Note 2: N215012, 215012, 216015, NR215012, 8215012.
