Front wheel bracket – Snapper NP216012 User Manual
Page 15
Front Wheel Bracket
Footnotes:
TP 400-5137-7-WB-N
Manual No.
7006059
21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
15
Part No
Description
Item
Qty
Note
1
7051886
ASSEMBLY, Arm Right Wheel
(Consists of Items 2,3,4,5A,6)
7051885
ASSEMBLY, Arm Left Wheel
(Consists of Items 2,3,4,5B,6)
2
7015761
BOLT, 5/16-18 x 3/4" Shoulder
3
7012325
LATCH, Height
4
7027702
GRIP, Latch
5A
7031017
ARM, Right Wheel (Round Hole)
5B
7031016
ARM, Left Wheel (Square Hole)
(Not shown)
6
7011791
RETAINER, 5/16 Bolt
7
7091601
NUT, 5/16-18 Hex Flange Lock, Grade 5
Was 91070
8
7074702
BRACKET, Front Wheel
Was 41770
9
7021119
AXLE
