Side Chute, Adapter
Footnotes:
TP 400-5137-7-WB-N
Manual No. 7006059 21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
39
Part No Description Item Qty Note
1 7051951 ASSEMBLY, Bag Adapter & Cover (European Models Only);
(Includes Items 2 thru 9)
2 7016107 ADAPTER, Grass Bag
3 7019287 COVER, Bag Adapter
4 7023000 HINGE, Chute Cover
5 7091064 5 BOLT, 1/4-20 x 1/2" Short Neck Carriage, Grade 5
6 7090053 5 WASHER, 1/4 Internal Tooth Lock Was 91023
7 7091576 5 NUT, 1/4-20 Hex, Grade 5 Was 91100
8 7032661 STOP, Cover
9 7023042 MOLDING, Trim
10A 7016050 ADAPTER, Grass Bag
10B 7058037 ASSEMBLY, Grass Bag Adapter (See "Accessory - Grass Bag"
illustration and parts; (Model
215014)
11 7024340 SPACER
12 7090951 NUT, 5/16-18 Hex Flange Center Lock
13 7011791 2 RETAINER, 5/16 Bolt
14 7091508 BOLT, 5/16-18 x 3/4" Short Neck Carriage, Grade 5 Was 90001
15 7042965 KIT, Side Chute Was 60955 (10 per box)
16 7090122 2 WASHER, 5/16 Flat Was 91514
17 7024085 2 WING-NUT, 5/16-18 Nyloc
18 7029149 COVER, 21" Deck
19 7090951 2 NUT, 5/16-18 Large Flange Center Lock (Model 215014)
