Slant/Fin B-200A User Manual
Page 5
Bobcat Model B-120A and B-200A
5
Figure 5. Non-direct vent, venting through the roof.
VENT
TERMINATION
3 IN. DIA.
VENT PIPE
AIR INTAKE
(DO NOT BLOCK)
Figure 6. Non-direct vent, utilizing an existing chimney as a chase.
CHIMNEY
TOP PLATE
3 INCH DIA.
VENT PIPE
3 INCH DIA.
VENT PIPE
AIR INTAKE
(DO NOT
BLOCK)
UNUSED
CHIMNEY
VENT
TERMINATION
