7 TP 400-2169-01-ZT-SMA
Front Column & Dash Group
1 1716002 2 GRIP, Control Handle
2 1717155 1 CONTROL LEVER ASSEMBLY, RH
3 1717154 1 CONTROL LEVER ASSEMBLY, LH
4 1717158 1 ENCLOSURE, Handrail, Front
5 1717157 1 ENCLOSURE, Handrail, Rear
6 1717167 4 SCREW, Self Tapping #10-24 x 1/2
7 1716073 1 HANDRAIL ASSEMBLY
8 1917372 6 NUT, Hex Hd. 5/16-18
9 1917356 6 LOCKWASHER, 5/16
10 1716079 2 KNOB, 5/16-18 x 4-3/8
11 1931333 4 BOLT, Carriage Sh. Nk. 5/16-18 x 3/4
12 1719376 1 DASH SUPPORT ASSEMBLY
13 1716004 1 SHAFT, Control Handles
14 928197 2 RING, “E” External #37
15 1933988 2 NUT, Push, 5/16
16 1930591 6 SCREW, Hex, Wz. Lk., 5/16-18 x 3/4
17 1931277 2 NUT, Hex, Wz. Fl., 5/16-18
18 8191045 2 SPRING
19 1919326 5 WASHER, Plain, 5/16
20 1716036 1 BAR, Stop
21 1919438 2 NUT, Hex Lock ESNA 5/16-18
22 1920470 2 NUT, Retainer Speed 5/16-18
23 1921719 2 CAPSCREW, Hex Hd. 5/16-18 x 2-1./2
24 1713588 2 SPACER
25 1717165 1 SPRING, Torsion, RH
25 1718272 1 SPRING, Torsion, LH
26 1935255 4 NUT, Pal, 5/16-18
27 1686750 1 HEADLIGHT KIT, Optional (with orange shroud - not shown)
27 1686751 1 HEADLIGHT KIT, Optional (with red shroud - not shown)
27 1715998 1 SHROUD, Front (without headlight)
28 1925003 3 SCREW, Hex Wash. Hd. Taptite, 1/4-20 x 1/2
29 1922611 1 WASHER
30 1665819 4 BUSHING
31 1713855 1 KNOB
32 1921319 1 WASHER, Plain 1/4
33 1715977 1 ROD, Parking Brake
34 1930642 1 NUT, Hex Flange Center Lock
35 1718758 1 PAD, Neoprene
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1692905 14HP, ZT Rider
1692906 16HP, ZT Rider
1692907 14HP, ZT Rider
1692908 16HP, ZT Rider
1692910 14HP, ZT Rider
1692911 16HP, ZT Rider
1693140 14HP, ZT Rider (Export)
1693143 16HP, ZT Rider (Export)
1693286 14HP, ZT Rider
1693288 16HP, ZT Rider
1693290 14HP, ZT Rider (Export)
1693292 16HP, ZT Rider (Export)
1693296 14HP, ZT Rider
1693298 16HP, ZT Rider
1693300 14HP, ZT Rider
1693302 16HP, ZT Rider
