5 TP 400-2169-01-ZT-SMA
Frame, Body & Fuel System Group
55 1708524 1 FOOTREST PAD, RH
56 1704351 14 FASTENER, Panel
57 1660347 1 FRAME ASSEMBLY
58 1718376 1 PANEL, Front
59 960208 2 WASHER, Plain
60 1704626 2 SPACER, Hood, Plastic
61 1705249 2 SPACER
62 1705248 2 PIVOT, Hood
63 1960373 2 CAPSCREW, Taptite, 5/16-18 x 1
64 1704628 2 CLIP
65 1935255 4 NUT, Pal, 5/16-18
66 1930591 4 CAPSCREW, Hex Flange Whiz Lock, 5/16-18 x 3/4
67 1716038 2 BUSHING, Upper
68 1704867 2 BEARING, Lower
69 921133 2 FITTING, Grease
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
Ref Nos 1-54 on previous page.
The above parts group applies to the following Mfg. Nos.:
1692905 14HP, ZT Rider
1692906 16HP, ZT Rider
1692907 14HP, ZT Rider
1692908 16HP, ZT Rider
1692910 14HP, ZT Rider
1692911 16HP, ZT Rider
1693140 14HP, ZT Rider (Export)
1693143 16HP, ZT Rider (Export)
1693286 14HP, ZT Rider
1693288 16HP, ZT Rider
1693290 14HP, ZT Rider (Export)
1693292 16HP, ZT Rider (Export)
1693296 14HP, ZT Rider
1693298 16HP, ZT Rider
1693300 14HP, ZT Rider
1693302 16HP, ZT Rider
