Simplicity ZERO TURN TP 400-2169-01-ZT-SMA - Manual (Page 29)

27 TP 400-2169-01-ZT-SMA
Drive System Update Kit - 1686752
1 1719385 1 PULLEY ASSY, PTO
2 171241 1 KEY, PTO Pulley
3 1719337 1 BELT GUIDE
4 1702488 2 RESERVOIR
5 933098 8 CLAMP, Spring
6 1719556 2 HOSE, RH, 21”
6 1719557 2 HOSE, LH, 26”
7 927731 2 RETAINING RING, 1/4-28 x 1/4
8 1928692 4 SET SCREW, Hex, 1/4-20 x 5/8
9 1925003 8 SCREW, Taptite,
10 930672 2 KEY, Drive Pulley
11 1719560 2 FITTING, 90°, Steel
12 1718875 2 FITTING, 90°, Plastic
13 1701011 3 TIE, 15”
14 1716098 1 DECAL, Oil Res.
15 1719381 1 V-BELT,
16 1719382 2 PULLEY ASSY, Trans.
17 1707433 1 SPACER, Carrier, Rear, 1 x 1/2 x 11/32
18 1709089 1 SPACER, Carrier, Front, 1 x 1/2 x 17/64
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1692905 14HP, ZT Rider
1692906 16HP, ZT Rider
1692907 14HP, ZT Rider
1692908 16HP, ZT Rider
1692910 14HP, ZT Rider
1692911 16HP, ZT Rider
1693140 14HP, ZT Rider (Export)
1693143 16HP, ZT Rider (Export)
1693286 14HP, ZT Rider
1693288 16HP, ZT Rider
1693290 14HP, ZT Rider (Export)
1693292 16HP, ZT Rider (Export)
1693296 14HP, ZT Rider
1693298 16HP, ZT Rider
1693300 14HP, ZT Rider
1693302 16HP, ZT Rider
