3 TP 400-2169-01-ZT-SMA
Frame, Body & Fuel System Group
1 1718851 1 SEAT, High Back, Replacement (**See Footnote)
2 1703900 1 SPACER
3 1718945 1 SUPPORT, Seat
4 1930642 9 NUT, Hex Flange Lock, 1/4-20
5 1919381 4 WASHER, Plain
6 1930591 2 CAPSCREW, Hex Lock, 5/16-18 x 3/4
7 1917356 1 LOCKWASHER, 5/16
8 1921977 2 CAPSCREW, Hex, 5/16-18 x 1-1/4
9 1917372 1 NUT, hex, 5/16-18
10 1708881 1 CAP, Vinyl
11 1708509 1 ADJUSTER, Seat
12 1667286 1 SPRING
13 1708511 4 SPACER, Seat Slide
14 1686638 1 DECK, Seat (Orange)
14 1714625 1 DECK, Seat (Red)
15 1673320 3 POP-RIVET
16 1708504 1 SCREEN
17 1960295 8 CAPSCREW, Hex Flange Lock, 1/4-20 x 5/8
18 1715961 1 SUPPORT, Reservoirs
19 1931277 9 NUT, Hex Flange Lock, 5/16-18
20 1716027 1 PLATE, Battery
21 1925003 6 CAPSCREW, Taptite, 1/4-20 x 1/2
22 1925205 2 CAPSCREW, Hex Hd, 5/16-18 x 5/8
23 1673796 1 SPACER
24 1922127 1 CAPSCREW, Hex Hd, 5/16-18 x 1-3/4
25 1715962 1 SHROUD, Rear
26 1714078 1 DUCT, Air Inlet
27 173206 1 FILTER, Fuel
28 1717666 1 SUPPORT, Seat Deck
29 1923341 1 CAPSCREW, Hex Hd, 1/4-20 x 3/4
30 1715970 2 BUMPER
31 1921333 1 CAPSCREW, Hex Hd, 5/16-18 x 1
32 1708363 1 SUPPORT, Fuel Tank
33 1931333 1 CARRIAGE BOLT, 5/16-18 x 1
34 1708362 1 STRAP, Fuel Tank, Brace
35 1714020 1 CAP, Fuel Tank
36 1685483 1 TANK, Fuel
37 1710437 1 SPACER
38 1924940 1 WASHER
39 1931202 1 CAPSCREW, Taptite Washer Head, 5/16-18 x 1-1/4
40 1654930 1 BUSHING, Rubber
41 1674231 1 FITTING, Elbow
42 1960112 2 CLAMP, Hose
43 1717551 1 HOSE
44 1933988 2 NUT, Push Pal, 5/16
45 1930591 2 CAPSCREW, Hex Flange Whiz Lock, 5/16-18 x 3/4
46 1708525 1 FOOTREST PAD, LH
47 1715999 1 SPINDLE ASSEMBLY, LH
48 1920328 1 CAPSCREW, Hex Hd, 1/2-13 x 1-1/2
49 1716064 1 HOOK, Mower
50 1709235 1 BUSHING
51 1930644 1 NUT, Flange Lock, 1/2-13
52 1715997 1 SPINDLE ASSEMBLY, RH
53 1919394 4 WASHER
54 934712 2 E-RING Retainer
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
Ref Nos 55 and above on following page.
** Original Seat and Arm Rests no longer available. Order replacement seat as shown.
The above parts group applies to the following Mfg. Nos.:
1692905 14HP, ZT Rider
1692906 16HP, ZT Rider
1692907 14HP, ZT Rider
1692908 16HP, ZT Rider
1692910 14HP, ZT Rider
1692911 16HP, ZT Rider
1693140 14HP, ZT Rider (Export)
1693143 16HP, ZT Rider (Export)
1693286 14HP, ZT Rider
1693288 16HP, ZT Rider
1693290 14HP, ZT Rider (Export)
1693292 16HP, ZT Rider (Export)
1693296 14HP, ZT Rider
1693298 16HP, ZT Rider
1693300 14HP, ZT Rider
1693302 16HP, ZT Rider
