23 TP 400-2169-01-ZT-SMA
Decals - Safety & Common
1 1719105 1 DECAL, Belt/Blade (under Seat Deck)
2 1717654 1 DECAL, Parking Brake
3 1715993 1 DECAL, Operating Instructions
4 1708927 1 DECAL, Logo, USA
5 1715996 1 DECAL, Transmission Release
6 1716098 1 DECAL, Oil Reservoir
7 1704276 1 DECAL, Danger, Rotating Cutting Blade
8 1704277 1 DECAL, Danger, Chute in Place
9 1704477 1 DECAL, Cutting Width, 38”
9 1704478 1 DECAL, Cutting Width, 44”
10 1717736 1 DECAL, Height of Cut
11 * 1 DECAL, OPEI (Not Serviced)
12 * 1 PLATE, Manufacturing No/Serial No (Not Serviced)
13 * 1 DECAL, Decibel (Export Only)
14 * 1 DECAL, CE (Export Only)
15 1717161 1 DECAL, Engine (14 HP Models - Not Shown)
16 1717162 1 DECAL, Engine (16 HP Models - Not Shown)
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
* Not a Servicable Part.
The above parts group applies to the following Mfg. Nos.:
1692905 14HP, ZT Rider
1692906 16HP, ZT Rider
1692907 14HP, ZT Rider
1692908 16HP, ZT Rider
1692910 14HP, ZT Rider
1692911 16HP, ZT Rider
1693140 14HP, ZT Rider (Export)
1693143 16HP, ZT Rider (Export)
1693286 14HP, ZT Rider
1693288 16HP, ZT Rider
1693290 14HP, ZT Rider (Export)
1693292 16HP, ZT Rider (Export)
1693296 14HP, ZT Rider
1693298 16HP, ZT Rider
1693300 14HP, ZT Rider
1693302 16HP, ZT Rider
1692912 38” Mower Deck
1692913 38” Mower Deck
1692914 44” Mower Deck
1692915 44” Mower Deck
