Unaligned projected image

The SMART V25 projector image can slip if the projector is moved often or installed in a location

prone to vibration, such as next to a heavy door. Follow these precautions to help prevent the image

from becoming misaligned:

l

Make sure that the installation wall is plumb and square and doesn’t move or vibrate

excessively.

l

Make sure that there are no obstructions behind the projector’s wall mount bracket, and that the

bracket is firmly secured to the wall according to the installation instructions.

l

Make sure that the knob and locking screw are tight.

l

Confirm that all cables are held in place with the appropriate cable clip.

l

Adjust the projected image. See the included SMART Board 480iv and 680iv Interactive

Whiteboard Systems Installation Guide (

smarttech.com/kb/153153

) and Adjusting the image

on page 18.

Accessing the service menu

C

  C A U T I O N

l

To prevent tampering or unintentional changes, only system administrators should access

the service menu. Do not share the service menu access code with casual users of your

interactive whiteboard system.

l

Do not adjust any settings in the service menu other than those listed in this guide. Changing

other settings can damage or affect the operation of your projector and invalidates your

warranty.

C H A P T E R 6

Troubleshooting your interactive whiteboard system

46
