CONNECTING A VCR OR DVD PLAYER
Switch off TV and external equipment before connecting cables. (Cables are not supplied.)
❶
Connect VCR, DVD Player, or other equipment’s Audio Video Out to the TV Audio Video
Input.
For Mono VCR (Single Audio Jack) connect VCR Audio Out to TV Audio (L) Input.
①
Optional
Connect DVD Player or other equipment’s S-Video Out to the TV S-Video In Jack.
Using the S-Video jack overrides the Video jack.
❷
Press POWER to turn on the TV. Turn on external equipment also.
❸
Press the INPUT key to select VIDEO1 or VIDEO2.
Note: Audio/Video Input (AV2) and Component inputs share the same audio (R/L) input
jacks.
Connect equipment to the component inputs or A/V2 inputs, but not both sets at the
same time.
USING THE AUDIO/VIDEO INPUT JACKS
QuickTips
■
Make sure all cable
connectors are fully
seated on jacks.
■
Always match A/V
cables according to the
colors;
RED
for right
audio,
WHITE
for left
audio and
YELLOW
for
video.
■
A solid Blue screen
with the word
VIDEO1 or VIDEO2,
displayed means that
the Video mode is
selected, but no
signal is being
detected at the
Video jacks. Check
connections, turn on
external equipment.
N
Neeeed
d h
heellp
p?
?
V
Viissiitt o
ou
urr W
We
eb
b ssiitte
e a
att
www.sanyoctv.com
o
orr C
Ca
allll 1
1--8
80
00
0--8
87
77
7--5
50
03
32
2
❶
B
Ba
acckk V
Viie
ew
w o
off V
VC
CR
R
❷
R
Re
em
mo
otte
e C
Co
on
nttrro
oll
T
TV
V A
AV
V IIn
np
pu
utt
JJa
acckkss
D
DV
VD
D P
Plla
ayye
err
①
①
W
Wh
ha
att yyo
ou
u w
wiillll n
ne
ee
ed
d ffo
orr cco
on
nn
ne
eccttiio
on
nss::
❶
A
AV
V C
Ca
ab
blle
e –
– 1
1
O
O
P
PT
TIIO
ON
NA
AL
L
C
C
O
ON
NN
NE
EC
CT
TIIO
ON
N
①
S
S--V
Viid
de
eo
o C
Ca
ab
blle
e –
– 1
1
①
A
Au
ud
diio
o C
Ca
ab
blle
e –
– 1
1
Press
INPUT key after
connecting cables.
❸
