CONNECTING A CABLE BOX AND VCR TO THE TV FOR PIP OPERATION
Cables are not supplied.
❶
Connect Cable system signal to a signal splitter.
❷
Connect RF cable from splitter to the TV 75 ohm input jack.
❸
Connect RF cable from splitter to the Cable Box In.
❹
Connect RF cable from the Cable Box out to the VCR “In from ant.”
❺
Connect VCR’s Audio Out (R/L) and Video Out to the TV Audio Input (R/L) and Video Input jacks.
❻
Press POWER key to turn on the TV. Turn on external equipment.
TO USE PIP:
1.
Press PIP ON/OFF key.
2. Press
the
SELECT key to select Video1 or Video2 for the PIP window.
3.
Refer to page 14 to operate PIP, if needed.
Note:
PIP feature will only function with a Cable Box system by using a splitter. Also, this connection enables you
to view premium channels while using the PIP feature.
❸
❷
T
TV
V B
Ba
acckk
❶
V
VC
CR
R B
Ba
acckk
PIP Cable Box Hookup
S
Sp
plliitttte
err
C
Ca
ab
blle
e B
Bo
oxx
B
Ba
acckk
C
CA
AB
BL
LE
E
❹
❺
W
Wh
ha
att yyo
ou
u w
wiillll n
ne
ee
ed
d ffo
orr cco
on
nn
ne
eccttiio
on
nss::
❶
S
Sp
plliitttte
err –
– 1
1
❷, ❸,
a
an
nd
d
❹
R
RF
F C
Ca
ab
blle
ess –
– 3
3
❺
A
AV
V C
Ca
ab
blle
e –
– 1
1
