26
PICTURE Menu
PICTURE Menu
Item Description
BRIGHTNESS
8VLQJWKHŸźEXWWRQVDGMXVWVWKHEULJKWQHVV
Light
Ù Dark
CONTRAST
8VLQJWKHŸźEXWWRQVDGMXVWVWKHFRQWUDVW
Strong
Ù Weak
GAMMA
8VLQJWKHŸźEXWWRQVVZLWFKHVWKHJDPPDPRGH
#1 DEFAULT Ù#1 CUSTOM Ù #2 DEFAULT Ù #2 CUSTOM Ù #3 DEFAULT
#5 CUSTOM Ù #5 DEFAULT Ù #4 CUSTOM Ù #4 DEFAULT Ù #3 CUSTOM
To adjust CUSTOM
Selecting a mode whose name includes
&86720DQGWKHQSUHVVLQJWKHŹEXWWRQ
or the ENTER button displays a dialog to aid
you in adjusting the mode.
This function is useful when you want to
change the brightness of particular tones.
&KRRVHDQLWHPXVLQJWKHŻŹEXWWRQVDQG
DGMXVWWKHOHYHOXVLQJWKHŸźEXWWRQV
You can display a test pattern for checking the effect of your
adjustment by pressing the ENTER button.
Each time you press the ENTER button, the pattern changes as
below.
No pattern Ö Gray scale of 9 steps
Ramp Õ Gray scale of 15 steps
The eight equalizing bars correspond to eight tone levels of the test
pattern except the darkest in the left end. If you want to adjust the
2nd tone from left end on the test pattern (Gray scale of 9 steps),
use the equalizing adjustment bar “1”. The darkest tone at the left
end of the test pattern cannot be controlled with any of equalizing
adjustment bar.
• When this function is performed, lines or other distortion may
appear.
From the PICTURE menu, items shown in the table below
can be performed.
Select an item using the
Ÿź cursor buttons on the
projector or remote control, and press the Ź cursor button
on the projector or remote control, or the ENTER button
on the remote control to execute the item. Then perform it
according to the following table
