CHARGED (green) LED lit: Indicates the battery is fully charged and the charger is
in maintain mode
.
NOTE: See the Operating Instructions section for a complete description of the charger
modes.
Digital Display
The Digital Display gives a digital indication of voltage or % of charge of the battery or
alternator output, depending on the Display Mode chosen. The display will show the
battery VOLTAGE when the charger is not charging a battery.
Display Mode Switch
Use this switch to set the function of the digital display to one of the following:
Battery %
•
- The digital display shows an estimated charge percentage of the battery
connected to the charger battery clips.
Voltage
•
– The digital display shows the voltage at the charger battery clips in DC
volts.
Alternator %
•
- The digital display shows an estimated output percentage of the
vehicle’s charging system connected to the charger battery clips as compared to a
properly functioning system.
Battery Type Switch
Use this switch to set the type of battery to be charged.
Regular
•
– Set the button to
.
Deep-Cycle
•
– Set the button to
.
AGM
•
– Set the button to
.
GEL
•
– Set the button to
.
Battery Size Selector Switch
Use the Battery Size selector switch to select the charge rate or engine starting setting
you require.
2A Small Charge Rate
•
– Intended for charging small batteries such as those
commonly used in garden tractors, snow mobiles and motorcycles. It can also be
used to maintain large batteries that are already fully charged.
10◄►25A Medium Variable Charge Rate
•
– Use for charging automotive,
marine and deep-cycle batteries.
80A Engine Start
•
– Provides 80 amps for cranking an engine with a weak or run
down battery. Always use in combination with a battery.
OPERATING INSTRUCTIONS
11.
This battery charger must be properly assembled in accordance with the
assembly instructions before it is used.
Charging
Ensure that all of the charger components are in place and in good working
1.
condition, for example, the plastic boots on the battery clips.
Connect the battery following the precautions listed in sections 6 and 7.
2.
Connect the AC power following the precautions listed in section 8. Make sure to
3.
place the charger on a dry, non-flammable surface like metal or concrete.
Select the appropriate settings for your battery.
4.
To disconnect, reverse the procedure.
5.
NOTE: This charger is equipped with an auto-start feature. Current will not be supplied
to the battery clips until a battery is properly connected. Meaning, the clips will not spark
if touched together.
Battery Connection Indicator
If the charger does not detect a properly connected battery, the CONNECTED LED will
not light. Charging will not begin if the CONNECTED LED is not on.
