58 Paper Handling
The following table provides a general guide for setting the adjustment lever.
Experiment with different settings until you find the one that gives you the print
quality you want.
Important!
Continuous use of the wrong adjustment lever setting can drastically reduce
the print head life. Position “-” is used only when the print quality is too light.
Setting the lever to position “-” when you are using thin paper may damage the
print head.
Automatic fanfold feeding
❏
See “Loading fanfold paper” on page 9 for details on using fanfold paper.
Paper Type Weight Per Sheet Thickness
Recommended
Position
Single-sheet
14 lbs (52 gsm) 0.06 mm 1
17 lbs (64 gsm) 0.08 mm 1
21 lbs (81 gsm) 0.10 mm 1
28 lbs (104 gsm) 0.13 mm 1
42 lbs (156 gsm) 0.19 mm 2
Multi-part
2-ply 11 lbs (40 gsm) 0.13 mm 2
3-ply 11 lbs (40 gsm) 0.20 mm 3
4-ply 11 lbs (40 gsm) 0.26 mm 4
5-ply 11 lbs (40 gsm) 0.33 mm 5
6-ply 11 lbs (40 gsm) 0.39 mm 6
7-ply 11 lbs (40 gsm) 0.45 mm 7
Labels — — 2
Envelope (#10) — — 5
