12
2-3-2. Outdoor Unit
DATA SUBJECT TO CHANGE WITHOUT NOTICE
4-way Valve (Solenoid coil) LB69001 (Coil), V26-9201 (Valve)
Coil rating AC 120V, 6W
Thermostat (Low temp. cutoff 23A) TRS02-M13MSR436
Operating temp. °F (°C) OFF (OPEN) : 5°F (–15°C)
ON (CLOSE) : 17°F (–8.3°C)
Thermostat (Defrost thermo. 23D) TRS02-12MSR
Operating temp. °F (°C) ON 54 ± 4°F (12 ± 2°C)
Diff. 14 deg (8 deg). below
Power Relay (PR) DFU24D1-F
Coil rating DC 24V
Coil resistance Ω at 68°F (20°C) 650 ± 10%
Contact rating AC 250V, 20A
PTC Thermistor PS2A E20-470
Resistance
Ω
at 77°F (25°C) 47 ± 25%
(2) Outdoor Unit CH1251
DATA SUBJECT TO CHANGE WITHOUT NOTICE
4-way Valve (Solenoid coil) LB69001 (Coil), VH79102 (Valve)
Coil rating AC 120V, 6W
Thermostat (Low temp. cutoff 23A) TRS02-M13MSR436
Operating temp. °F (°C) OFF (OPEN) : 5°F (–15°C)
ON (CLOSE) : 17°F (–8.3°C)
Thermostat (Defrost thermo. 23D) TRS02-12MSR
Operating temp. °F (°C) ON 54 ± 4°F (12 ± 2°C)
Diff. 14 deg (8 deg). below
Power Relay (PR) DFU24D1-F
Coil rating DC 24V
Coil resistance Ω at 68°F (20°C) 650 ± 10%
Contact rating AC 250V, 20A
PTC Thermistor PS2A E20-470
Resistance
Ω
at 77°F (25°C) 47 ± 25%
(1) Outdoor Unit CH0951
