May 2002 T-38324-A Page 8-1
8. Maintenance/Troubleshooting
Maintenance of the CS4000 Mini Controller with Ethernet consists of replacing fuses and cleaning the
enclosure window. The Troubleshooting section of this chapter gives possible solutions to problems
and describes how to locate a malfunction in the Ethernet network.
Replacement Parts
If, at any time, you need to replace or order new parts for your CS4000 Mini Controller with Ethernet
you can select from any item in Table 8-1.
Table 8-1. Replacement Parts
Quantity Description Part Number
1 27A Tool Control Module (TCM) 49-4100-03C5
1 8A Tool Control Module (TCM) 49-4100-01CL5
1 +24V DC Power Supply 12-20-5007
1 Ethernet Interface Card 420959-38093
1 Fuse 1ASB, Littelfuse 39001 5x20 mm 13-10-61001
2 Fuse .5pico, Littelfuse 255.500 13-10-4050
1 Limit Selector Switch Amp Part Number 436037-1
16-30-0940
1 Backplane 420890-35327
1 I/O Connector Module Assembly 244000-38183
1 Interbus-S Module Weiland Part Number 83.031.1300.1
41-30-0300
NOTE: All part numbers used in Table 8-1 are GSE tech-motive tool
part numbers unless otherwise specified.
