Cutting deck, blade – Snapper EMRP216518B User Manual
Page 9
CUTTING DECK, BLADE
Footnotes:
TP 400-5043-1-WB-N
Manual No.
7006138
21" STEEL DECK WALK BEHIND MOWER
"MR" SERIES 18
9
Part No
Description
Item
Qty
Note
1
7057884
1
* ASSEMBLY, M Series Push 21” Deck
Was 57784 (Used on
MR216518B)
--
7057884
1
* ASSEMBLY, Non-Adjustable Air, 21” Deck
Was 57667 (Used on
MRP216518B and
EMRP216518B)
2
7091601
10
NUT, 5/16-18 Hex Flange Lock, GR5
Was 90585
3
7090731
9
BOLT, 5/16-18 x 1/2” Short Neck Carriage GR5
Was 92061
4
7091169
1
BOLT, 5/16-18 x 1-1/8” Short Neck Carriage GR5
5
7090324
3
SCREW, 3/8-16 x 1” Hex Washer Self-Tap
6
7090167
1
SCREW, 3/8-24 x 2” Hex Head Cap, GR5
7
7012063
2
WASHER, Cone
8
7026407
1
BLADE, 21” Ninja
9
7015626
1
HUB, Blade Drive 25mm
10
7091214
1
KEY, Hi-Pro #HP506 (Briggs engine)
11
7090201
1
SCREW, 5/16-18 x 5/16” Hex Socket Head
12
7015780
1
PULLEY, Engine Drive (25mm x 2-1/8” O.D.)
13
7090702
1
BOLT, 5/16-18 x 2-1/4” Hex Flange Lock
14
7091508
2
BOLT, 5/16-18 x 3/4” Short Neck Carriage GR5
Was 90001
15
7011791
1
RETAINER, 5/16” Bolt
16
7090951
2
NUT, 5/16-18 Hex Large Flange Center Lock
17
7091122
6
SCREW, 1/4-20 x 1/2” Hex Washer Self-Tap
Was 90539
18
7031961
1
WASHER, 7/16” Flat
19
7073462
1
DECAL, Caution, International Symbols
used on Euro models
20
7046780
2
HOLE PLUG, Polyethylene
21
7074568
1
COVER, Belt
used on MRP216518B &
EMRP216518B
22
7044770
3
SPACER, .06 Blade Hub
23
7041400
1
FENDER WELDMENT
used on Euro models
24
7046471
3
PLUG, 5/16” Square Hole
used on Push models; (only one
shown)
25
7045264
3
PLUG, 5/16” Round Hole
qty. 3 on Push, qty. 2 on Self-
Propelled (only one shown)
26
7013320
1
BUSHING, .388 x .625 x 1.62
used on Euro models
27
7031961
2
WASHER, 7/16” Flat
used on Euro models
28
7033863
1
COVER, Belt- IP21S
used on Euro models
29
7090534
1
SCREW, 5/16-18 x 1/2” Hex Head Cap, GR5
used on Euro models
--
--
1
*ENGINE, 6.5 B&S Quantum
model 123K02 type 0119 trim E1
--
--
1
*ENGINE, B&S Euro 6.5HP
model 123K02 type 0125 trim E1
Note* includes painted deck and wheel brackets
Note* Purchase engine parts from engine manufacturer dealer.
