Side chute, adapter – Snapper EMRP216518B User Manual
Page 25
SIDE CHUTE, ADAPTER
Footnotes:
TP 400-5043-1-WB-N
Manual No.
7006138
21" STEEL DECK WALK BEHIND MOWER
"MR" SERIES 18
25
Part No
Description
Item
Qty
Note
1
7051951
--
ASSEMBLY, Bag Adapter & Cover
(Includes items 2 thru 9; used on
European Models Only)
2
7016107
1
ADAPTER, Grass Bag
3
7019287
1
COVER, Bag Adapter
4
7023000
1
HINGE, Chute Cover
5
7091064
5
BOLT, 1/4-20 x 1/2” Short Neck Carriage GR5
6
7090053
5
WASHER, 1/4” Internal Tooth Lock
Was 91023
7
7091576
5
NUT, 1/4-20 Hex
Was 91100
8
7032661
1
STOP, Cover
9
7023042
1
MOLDING, Trim
10A
7016050
1
ADAPTER, Grass Bag
10B
7058037
--
ASSEMBLY, Grass Bag Adapter
(See Grass Bag Accessory
page)
11
7024340
1
SPACER, .316 I.D. x .375 O.D. x .310 thick
12
7090951
1
NUT, 5/16-18 Hex Large Flange Center Lock
13
7011791
1
RETAINER, 5/16” Bolt
14
7091508
2
BOLT, 5/16-18 x 3/4” Short Neck Carriage GR5
Was 90001
15
7042965
1
CHUTE, Side
16
7090122
2
WASHER, 3/8" Flat
Was 91514
17
7024085
2
WING-NUT, 5/16-18 Nyloc
18
7029149
1
COVER, 21” Deck
