DRIVE SYSTEM SELF-PROPELLED
Footnotes:
TP 400-5043-1-WB-N
Manual No.
7006138
21" STEEL DECK WALK BEHIND MOWER
"MR" SERIES 18
15
Part No
Description
Item
Qty
Note
1
7012354
1
BELT, Poly-Vee
2
7034179
1
LINK, Differential (Commercial)
--
7051921
1
ASSEMBLY, Clutch Idler
(includes items 3 thru 7)
3
7032832
1
ARM, Clutch Idler
4
7012124
1
PULLEY, Idler
5
7091025
1
SCREW, 1/4-28 x 1-3/8” Hex Head Cap GR5
6
7090303
1
NUT, 1/4-28 Hex Top Lock
7
7012117
2
BUSHING, 3/8” Plastic
8
7072284
1
SHAFT, Hex Drive
9
7024521
1
PULLEY, Poly-V, 2” O.D.
Non-Commercial Models
10
7012316
1
WASHER, 3/8” Flat
11
7012126
1
SPRING, Idler, Torsion
12
7012111
1
STUD, Idler (3/8-24 thread)
13
7031873
1
HOLDER, Half
14
7028014
1
BALL BEARING, .38 I.D. Spherical O.D.
15
7011025
1
O-RING
16
7090289
1
NUT, 3/8-24 Hex Center Lock GR5 or B
17
7031809
1
HOLDER, Half
18
7010937
1
CLIP, Transfer Rod 1/4”
also shown on HANDLES AND
CONTROLS page
19
7023790
1
ROD, Transfer
also shown on HANDLES AND
CONTROLS page
--
7051698
1
ASSY., Transfer Rod
Euro; also shown on HANDLES
AND CONTROLS page
20
7046784
1
BELT, Engine Drive 3L (Stretch)
--
7053225
1
ASSEMBLY, Driven Disc (Cantilever)
used on Euro Self-Propelled
models
21
7035477
1
THRUST PLATE, Short
22
7010746
2
RING, 5/8” External Retaining
used on Self-Propelled models
23
7026693
1
BALL BEARING, 3/4” I.D.
used on Self-Propelled models
24
7010121
1
WASHER, 3/4” Shim
25
7032664
1
SHIELD, Hex Shaft
26
7015753
1
BALL JOINT, 1/4-28
also shown on HANDLES AND
CONTROLS page
27
7090095
1
NUT, 1/4-28 Hex
also shown on HANDLES AND
CONTROLS page
28
7015752
1
LINK, Transfer
also shown on HANDLES AND
CONTROLS page
29
7010121
1
WASHER, 3/4” Shim
30
7090390
3
WASHER, 3/8” Internal Tooth Lock
31
7090122
1
WASHER, 3/8” Flat
32
7091630
1
NUT, 3/8-24 Hex
33
7091511
1
NUT, 5/16-18 Hex, GR5
Was 90196
34
7090187
1
WASHER, 5/16” Split Lock
