Snapper EMRP216518B - Manual (Page 19)

TRANSMISSION (DIFFERENTIAL)
Footnotes:
TP 400-5043-1-WB-N
Manual No. 7006138 21" STEEL DECK WALK BEHIND MOWER
"MR" SERIES 18
19
Part No Description Item Qty Note
-- 7053943 1 ASSY, Transmission- 1996 (Includes items 1 thru 30)
1 7092062 1 NUT, 5/16-24 Hex Lock
2 7092063 1 WASHER, Bellville
3 7019213 1 PULLEY, Poly-Vee Belt
4 7011724 2 WASHER, Spring
5 7053941 1 ASSY, Right Housing (Phantom) (Includes items 6, 7, 8, 9, 10 &
30)
6 7029034 1 HOUSING, Right Side
7 7014155 3 SCREW, 5/16-24 x 1-1/8” Rib Neck, GR5
8 7012314 1 SEAL, 5/8” Internal Diameter
9 7029035 1 BEARING, Tapered- (Differential Housing)
10 7073963 1 BALL BEARING, 7/16 I.D., 1/1/8” O.D.
11 7016544 1 PLUG, Transmission
12 7050767 1 GEAR, Input
13 7051932 1 ASSEMBLY, Short Axle
14 7012495 1 GEAR, Differential (46 tooth)
15 7031970 2 PLATE, 46T Gear
16 7031965 2 WASHER, Thrust, 3/4” I.D.
17 7090557 4 SCREW, #10-32 x 1-1/2” Hex Head Cap GR5 only 1 shown
18 7011774 1 GASKET, Housing
19 7090189 3 WASHER, 5/16” Internal/External Tooth Lock only 1 shown
20 7051903 1 BRACKET, Differential
21 7091825 4 SCREW, 1/4-20 x 1” Hex Washer Self-Tap Was 92064 (only 1 shown)
22 7012543 1 SPACER, Axle Gear
23 7051933 1 ASSEMBLY, Long Axle
24 7021115 4 GEAR, Pinion (12 tooth)
25 7012500 4 SPACER, Pinion Gear
26 7011110 4 SHAFT, Pinion
27 7090376 4 NUT, #10-32 Hex Nyloc
28 7053938 1 ASSY, Left Housing (Phantom) (Includes items 8, 9 & 29)
29 7029033 1 HOUSING, Left
30 7024442 3 GASKET, 5/8” O. D.
-- 7061017 * “OO” Grease (32 oz.)
Note* Maximum capacity of transmission case is 4 oz. DO NOT OVERFILL Transmission!
