DRIVE SYSTEM SELF-PROPELLED

Footnotes:

TP 400-5043-1-WB-N

Manual No.

7006138

21" STEEL DECK WALK BEHIND MOWER

"MR" SERIES 18

17

Part No

Description

Item

Qty

Note

35

7090316

1

BOLT, 5/16-18 x 3/4” Short Neck Carriage GR5

Was 91097

36

7032831

1

CONNECTOR, Transfer Rod

37

7091294

1

WASHER, .28 x .63 x .06 Flat

used on Euro Self-Propelled
models

38

7017696

1

BUSHING

39

7029025

1

SPRING, Wheel Drive

40

7012125

1

GUIDE, Thrust Plate (3/8-24 thread)

41

7013847

1

RETAINER, 3/8” Bolt

42

7090799

1

BOLT, 5/16-18 x 5/8” Short Neck Carriage GR5

Was 91026

43

7041855

1

DISC, Driven (Cantilever)

--

7059462

1

ASSY, Deck Bracket (Includes items 44A & 45)

44A

7033774

1

BRACKET, Deck

Was 31919 (Now 17696 +
33774)

44B

7057922

1

BRACKET, Deck, Painted Black Texture

used on Euro Self-Propelled
models

45

7012117

2

BUSHING, 3/8” Plastic

46

7021758

1

SPACER

used on Commercial models

47

7090534

1

SCREW, 5/16-18 x 1/2” Hex Head Cap, GR5

48

7090391

1

WASHER, 5/16” Internal Tooth Lock

49

7011724

1

WASHER, .44 x .78 x .025 Curved

50

7091597

1

PIN, 3/32 x 1/2” Cotter

Was 90555

51

7091122

2

SCREW, 1/4-20 x 1/2” Hex Washer Self-Tap

Was 90539

52

7090731

3

BOLT, 5/16-18 x 1/2” Short Neck Carriage GR5

53

7091601

2

NUT, 5/16-18 Hex Flange Lock, GR 5

Was 91070

54

7012122

1

SPRING, Clutch

55

7090053

1

WASHER, 1/4” Internal Tooth Lock

used on Euro Self-Propelled
models

56

7061275

--

KIT, Drive Disc Assembly

(Includes Drive Disc and items
32 & 38)
