HANDLES AND CONTROLS
Footnotes:
TP 400-5043-1-WB-N
Manual No. 7006138 21" STEEL DECK WALK BEHIND MOWER
"MR" SERIES 18
7
Part No Description Item Qty Note
34 7091576 3 NUT, 1/4-20 Hex Was 91100 (used on All)
35 7012080 1 CABLE-TIE, 7” used on All
36 7014343 4 BUSHING, .27 x .35 x .4 Flange used on Self Propelled
37 7023792 1 PIN, Clutch Handle used on Self Propelled
38 7091020 1 PUSH-NUT, 1/4” (for handle pin) used on Self Propelled
39 7029782 1 DECAL, OPC Bail (International Symbol) used on All; see Decal page
40 7028488 1 GUIDE, Rope (1/4-20 thread) used on All
41 7022458 1 FOAM GRIP, 15”, 21 SP used on All
42 7024087 1 DECAL, Speed Sector used on MRP216518B; see
Decal page
43 7029783 1 DECAL, Speed Sector Int'l Symbol used on EMRP216518B; see
Decal page
44 7076978 1 NUT, 1/4-28 Hex GR5 or B used on All
45 7090391 4 WASHER, 5/16” Internal Tooth Lock used on All
46 7026219 1 CLAMP, 7/8” Double Cable used on Self Propelled
47 7029911 1 LEVER, Speed Control used on Self Propelled
