Section 8
ELECTRICAL SYSTEM - KUBOTA DIESEL
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
481176-10
481176-11
462011
481808
*
483162
48798
48017-03
48017-04
483356
481638
481183
481805
481184
462013
9240
04010-11
04021-01
483629
48298
483627
04010-01
04020-01
04031-01
483013
04001-01
04030-02
451879
04110-01
462069
483360
423674
481811
04001-01
482784
04002-17
483355
48030-09
48030-10
481335
04031-03
481182
481826
483571
482588
483642
483643
483641 Cable, Positive Battery
Cable, Negative Battery
Clutch, Electric PTO
Module, Interlock
Battery (not available through Scag)
Switch, PTO
Switch, Key (Incl. Nut and Lockwasher)
Nut, 5/8-32 Special
Lockwasher 5/8”
Cable, Control (Throttle)
Switch, Seat
Gauge, Water Temperature
Gauge, Oil Pressure
Gauge, Voltmeter
Panel, Instrument Panel
Cup Holder Accessory (Incl. 16, 30, 32)
Screw, #10-32 x 1.5” Phillips
Nut, #10-32 Elastic Stop
Fuse Holder
Fuse, 20 Amp
Harness, Wiring
Screw, #10-32 x .5” Phillips
Nut, Hex #10-32
Lockwasher #10
Relay
Bolt, Hex Hd. 1/4-20 x .75”
Lockwasher 1/4”
Base, Instrument Panel
U-Nut, 1/4-20
Key Assembly w/Fob
Sender Unit, Water Temperature
Cup Holder Mounting Bracket
Sender Unit, Oil Pressure
Bolt, Hex Hd. 1/4-20 x 3/4”
50 Amp Breaker
Bolt, Hex Hd. M8-1.25 x 14mm
Hour Meter
Clamp, Cable .5” ID
Clamp, Cable .75” ID
Boot, Positive Battery Terminal
Washer, Star
Indicator Light, Glow Plugs
Relay, 40 Amp
Cover, Sealed Double
Clip, Wire
Double Fuse Assembly, Sealed (Incl. items 17, 18, 41, 42)
Cover, Sealed Single
Single Fuse Assembly, Sealed (Incl. items 17, 18, 42, 44)
