SPECIFICATIONS

General Specifications

Recording method

Dual-azimuth 2-head rotating helical scanning system

Audio recording

In 3-, 12-, and 24-hour modes

Tape speed

23.39 mm /sec (3-hour mode)

Specified video cassette tape

VHS 1/2 inch

Recording/playback time

3, 12, and 24 hours (when using E-180 tape)

Fast forward/rewind time

approximately 2 minutes 45 seconds (when using E-180 tape)

Standard

CCIR PAL colour

Video

Recording method

Luminance signal: FM recording
Chrominance signal: Down-converted direct recording

Video input

1 Vp-p, BNC, 75

, unbalanced

Video output

1 Vp-p, BNC, 75

, unbalanced

Horizontal resolution

Black & white mode

350 line or more

Colour mode

250 line or more

Audio

Input

–8 dBs, RCA pin jack, 27 k

, unbalanced

Output

–8 dBs, RCA pin jack, 600

, unbalanced

Microphone input

–60 dBs, 3.5 mm mini jack, 10 k

, unbalanced

Connectors

Alarm input

Low level active (0V)

Alarm output

DC 5 V (

±

0.5)/5.7 k

, Low at alarm

Tape end output

DC 5 V (

±

0.5)/5.7 k

, Low at tape end

Warning output

DC 5 V (

±

0.5)/5.7 k

, Low at warning

Switch output

DC 5 V (

±

0.5)/5.7 k

, Low at switching

Ext timer input

Low level active (0V)

DC 12 V “+” input

DC 12 V

DC 12 V “–” input

DC 0 V

Common

0 V (GND)

Remote control input

3.5 mm mini jack

DC 12 V input

Mini jack

Other Specifications

Operating temperature range

5°C to 40°C

Operating humidity range

80% or less

Power requirements

DC 12 V (10 V to 16 V)

Power consumption

14 W

Dimensions

240 (W) x 96.5 (H) x 335 (D) mm

Weight

approximately 3.8 kg

NOTE:

The specifications and external appearance of this unit are subject to change without notice.
