Page 24
25
1
46802
Upper Handle Wlmt. W/Decals
x
x
1
46857
Upper Handle Wlmt. W/Decals
x
x
x
x
2
42675
Quadrant, Speed Control
x
x
x
x
3
04062-02 Hairpin, .094 x 1.19
x
x
x
x
4
45282
Lever, Speed Adjustment
x
x
x
x
5
43086
Bushing, Speed Adjustment Lever
x
x
x
x
6
04001-20 Hex Head Bolt, 3/8-16 x 1-1/2"
x
x
x
x
7
48493-01 Ball Plunger
x
x
x
x
8
48092
Knob, Speed Adjustment
x
x
x
x
9
04014-01 Capscrew, 1/4-20 x 3/4" FHHS
x
x
x
x
10
04021-08 Nut, 1/4-20 Elastic Stop
x
x
x
x
11
04021-10 Nut, 5/16-18 Elastic Stop
x
x
x
x
12
04010-01 Screw, #10-32 x 1/2" PW HD
x
x
x
x
13
481071
Throttle Control
x
x
x
13A
48946
Throttle Control
x
14
04019-01 Nut, #10-32 Serr. Flange
x
x
x
x
15
48312
Bushing
x
x
x
x
16
45572
Handle, Operator Presents-RH
x
x
x
x
16A
45571
Handle, Operator Presents-LH (20") x
x
x
x
16A
45573
Handle, Operator Presents-LH (16") x
x
17
48787
Switch,Elec.Clutch Eng. (incl.Nut)
x
x
x
x
18
481076
Wire Harness, Manual Start
x
x
x
18A
481055
Wire Harness, Electric Start
x
x
x
19
48609
Key Switch, Manual Srt. (incl. Hwd) x
x
x
19A
48798
Key Switch, Elec. Start (incl. Hwd.) x
x
x
20
42257-01 Neutral Latch-RH
x
x
x
x
20A
42257-02 Neutral Latch-LH
x
x
x
x
21
48717
Switch, Neutral Interlock
x
x
x
x
22
48159
Grip
x
x
x
x
23
04032-01 Washer, Curved Spring
x
x
x
x
24
04040-15 Flat Washer
x
x
x
x
25
04031-08 Lock Washer,1/4" Int. Tooth
x
x
x
x
26
04001-17 Hex Head Bolt, 5/16-18 x 2"
x
x
x
x
27
04001-53 Hex Hd. Bolt, 5/16-18 x 2-1/2"
x
x
x
x
28
46744
Lever, Steering Control (incl. 29)
x
x
x
x
29
48492
Grip, Steering Control
x
x
x
x
30
44050
Rod, Steering Control
x
x
x
x
31
48951
Spring, Handle Return
x
x
x
x
32
04017-27 Capscr., 3/8-16 x 1" Ser. Flange
x
x
x
x
33
04030-02 Lock Washer, !/4"
x
x
x
x
34
04019-04 Nut, 3/8-16 Serr. Flange
x
x
x
x
35
44051
Rod Steering Control
x
x
x
x
36
45279
Bellcrank, Speed Control
x
x
x
x
37
04012-02 Setscrew, 1/4-28 x 1/4"
x
x
x
x
38
46335
Cam, Speed Control (incl. SS)
x
x
x
x
39
43166
Jackshaft, Speed Control
x
x
39A
43155
Jackshaft, Speed Control
x
x
x
x
40
04063-13 Key, 1/8 x 1/2" Woodruff
x
x
x
x
41
04021-10 Nut, 3/8-16 Elastic Stop
x
x
x
x
42
46336
Pivot, Pump Ctrl. (incl.Bshg & Zrk)
x
x
x
x
43
48100-04 Bushing, 1/2" ID
x
x
x
x
44
04017-17 Capscrew, 5/16-18 x 1" Serr. Flg.
x
x
x
x
45
04019-03 Nut, 5/16-18 Serrated Flange
x
x
x
x
46
42730
Bar, Speed Control
x
x
x
x
47
43161
Spacer, Speed Ctrl. Bearing
x
x
x
x
48
48409
Bearing, Speed Ctrl. Bellcrank
x
x
x
x
14KA 14KH 16BV 20CVE
Ref. Part
14KAE 16BVE
No. No. Description
18BV
14KA 14KH 16BV 20CVE
Ref. Part
14KAE
16BVE
No. No.
Description
18BV
HANDLE ASSEMBLY
* Common hardware which should be purchased locally. All bolts Grade 5 plated, all other fasteners zinc plated.
49
04001-69 Hex Head Bolt, 5/16-18 x 1-3/4"
x
x
x
x
50
48494-02 Spring, Return
x
x
x
x
51
481092-01 Knob, Plastic
x
x
x
x
52
43308
Bushing
x
x
x
x
53
45292
Handle, Neutral Adj
x
x
x
x
54
04065-05 Drive Pin, 5/32 x 7/8 Type U
x
x
x
x
55
04001-08 HH Bolt,5/16-18 x 3/4"
x
x
x
x
56
04030-03 Lock Washer, 5/16
x
x
x
x
57
04019-03 Nut, 5/16-18 Serr. Flange
x
x
x
x
58
48224
Bearing, Ball Neutral Return
x
x
x
x
59
46747
Cam, Neutral (incl. grease ftng.)
x
x
x
x
60
48114-05 Grease Fitting, 1/4-28 UNF
x
x
x
x
61
04050-01 Retaining Ring, 5/8 Ext. "E"
x
x
x
x
62
04001-09 Hex Head Bolt, 5/16-18 x 1"
x
x
x
x
63
45295
Shaft, Pump Control-LH
x
x
x
x
63A
45283
Shaft, Pump Control-RH
x
x
x
x
64
45642
Bellcrank, Pump Control-LH
x
x
x
x
64A
45643
Bellcrank, Pump Control-RH
x
x
x
x
65
04050-10 Retaining Ring, 1/2 Ext. "E"
x
x
x
x
66
48026
Switch, Neutral Start
x
x
x
x
67
By Ref.
Deck, Engine
x
x
x
x
68
04001-10 Hex Head Bolt, 5/16-18 x 1-1/4"
x
x
x
x
69
481278
Choke Control
x
69A
481072
Choke Control
x
70
481057
Spring, Return
x
x
x
x
71
42413
Fuse Holder
x
x
x
x
72
43306
Swivel Joint, Steering Rod
x
x
x
x
73
04040-04
Flat Washer (.344 x .688 x .065)
x
x
x
x
74
48298
Blade Fuse, 20A
x
x
x
75
04021-01 Nut, #10-32 Elastic Stop
x
x
x
76
04010-03 Screw, #10-32 x 1-1/2" Phillips
x
x
x
77
43305
Pin, Neutral Lock
x
x
x
x
78
43032
Swivel Joint
x
x
x
x
