Scag Power Equipment SWZ - Manual (Page 20)

21
Ref. Part
No. No.
Description 48 52 61 72
1 46851 Cutter Deck (Includes decals) x
1 46751 Cutter Deck (Includes decals) x
1 46752 Cutter Deck (Includes decals) x
1 46608 Cutter Deck (Includes decals) x
2 46631 Spindle Assembly x x x x
3 43296 Sleeve, Cutter Spindle x x x x
4 48924 Pulley x x x x
5 481022 Tapered Bearing (two) x x x x
6 43294 Spindle Housing x x x x
7 48114-04 Grease Fitting Str. 1/4-28 x x x x
8 43298 Spindle Shaft x x x x
9 45037 Idler Pivot x x x x
10 04063-08 Key, 1/4 x 1/4 x 2" x x x x
11 43278 Spacer, Cutter Blade x x x x
12 04001-10 Hex Head Bolt, 5/16-18 x 1-1/4" x x x x
13 481050 Spring, Chute Return x x x x
14 04019-03 Nut, 5/16-18 Serr. Flange x x x x
15 48110 Cutter Blade 16-1/2" x
15 48108 Cutter Blade 18" x
15 48111 Cutter Blade 21" x
15 48112 Cutter Blade 24" x
15A 48184 Cutter Blade 16-1/2" High Lift x
15A 48185 Cutter Blade 18" High Lift x
15A 48304 Cutter Blade 24" High Lift x
16 04040-10 Flat Washer, (.688 x 1.75 x .134) x x x x
17 04040-41 Hex Head Bolt, 5/8-11 x 9-1/2" x x x x
18 46079 Caster Assy. (incl. 19-28) x x x x
19 04066-01 Quick Pin x x x x
20 43037-01 Spacer, Caster Yoke, 1/2" Thick x x x x
21 48100-01 Bushing, 5/8 x 1", Flanged x x x x
22 48677 Relief Fitting, Cutter Spindle x x x x
23 46082 Support Assy., (incl. 21-23) x x x x
24 45006 Caster Yoke x x x x
25 43022 Sleeve, Caster Wheel Bearing x x x x
26 04001-37 Hex Head Bolt, 1/2-13 x 5-1/2" x x x x
27 04021-07 Nut, 1/2-13 Elastic Stop x x x x
28 48307 Wheel Assy. , (incl. 29-34,81) x x x x
29 48307-02 Tire Only, Caster Wheel x x x x
NS 48006-03 Inner Tube Only, Caster Wheel x x x x
30 48307-04 Rim Pair, Caster Wheel x x x x
31 48006-07 Bearing Retainer, Caster Wheel x x x x
32 48006-06 Roller Bearing, Caster Wheel x x x x
33 48114-03 Grease Fitting 45 Deg., 1/4-28 x x x x
34 48006-05 Hub Assy., (incl. Bolts) x x x x
35 04017-16 Capscrew, 5/16-18 x 3/4" x x x x
36 46726 Discharge Chute x x
36A 46725 Discharge Chute x x
37 04021-10 Nut, 5/16-18 Elastic Stop x x x x
38 04001-09 Hex Head Bolt, 5/16-18 x 1" x x x x
39 46798 Belt Cover, (incl. Decals) x
39 46804 Belt Cover, (incl. Decals) x
39 46805 Belt Cover, (incl. Decals) x
39 46848 Belt Cover, (incl. Decals) x
40 04041-07 Flat Washer, (.391 x .938 x .105) x x x x
41 04029-03 Wing Nut, 3/8-16 x x x x
42 48924 Pulley x x
42A 48753 Pulley x
42B 48967 Pulley x
43 48926 Tapered Hub x x x x
44 04001-01 Hex Head Bolt, 1/4-20 x 3/4". x x x x
45 04020-09 Nut, 5/8-11 Hex Head x x x x
46 48923 Pulley, Double x x
48", 52", 61", & 72" CUTTER DECKS
Ref. Part
No. No.
Description 48 52 61 72
* Common hardware which should be purchased locally. All bolts Grade 5 plated, all other fasteners zinc plated.
46a 48940 Pulley, Double x
46B 48966 Pulley, Double x
47 48087 Belt,RH Blade Drive x
47 48285 Belt,RH Blade Drive x
47 48265 Belt,RH Blade Drive x
47 48295 Belt,RH Blade Drive x
48 48089 Belt, Blade Drive x
48 48286 Belt, Blade Drive x
48 48088 Belt, Blade Drive x
48 48296 Belt, Blade Drive x
49 04021-05 Nut, 3/8-16 Centerlock x x x x
50 04019-04 Nut, 3/8-16 Serr. Flange x x x x
51 04021-09 Nut, 3/8-16 Elastic Stop x x x x
52 04004-02 Support, Belt Cover x x x x
53 04001-08 Hex Head Bolt, 5/16-18 x 3/4" x x x x
54 04017-42 Capscrew, 7/16-14 x 1" Serr. x x x x
55 04019-05 Nut, 7/16-14 Serr. Flange x x x x
56 04041-08 Flat Washer, 3/4 Special x x x x
57 44078 J-Hook x x x x
58 48181 Idler Pulley, "V" Groove x x x x
59 04050-02 Retaining Ring, 3/4" Ext. "E" x x x x
60 46081 Idler Arm Assy. (incl. 22 & 61) x x x x
61 48100-05 Bushing, 3/4 x 1/2 x x x x
62 43028 J-Hook, Idler Pulley x x x
62A 44078 J-Hook, Idler Pulley x
63 43077 Spacer, Pulley x x x x
64 04041-12 Flat Washer, 3/8 x 1-1/2 x 16 Ga. x x x x
65 04001-46 Hex Head Bolt, 3/8-16 x 2-1/4" x x x x
66 481024 Seal, Cutter Spindle x x x x
67 46748 Idler Arm Assy., (incl. 22 & 77) x x x x
68 43277 Spacer, J-Hook x x x x
69 481035 Nut, Cutter Spindle x x x x
70 43312 Spacer, Outside x x x x
71 43297 Spindle Bushing x x x x
72 04030-03 Lock Washer, 5/16" x x x x
73 04001-108 Hex Head Bolt, 5/16-18 x 4-1/4" x x x x
74 04001-77 Hex Head Bolt, 3/8-16 x 3-1/2" x x x x
75 45329 Idler Pivot x x x x
76 48269 Idler Pulley, Clutch Belt x x x x
77 48100-02 Bushing, 1-1/8 x 1.0 Flanged x x x x
78 04050-05 Retaining Ring,1-1/8 Ext. "E" x x x x
79 48038 Guide, Roller x x x
80 45046 Roller Shaft x x x
81 04040-15 Flatwshr., 5/16 (.375 x .875 x .083) x x x x
82 48307-08 Nut, 5/16-24 Tapered x x x x
83 48098 Shield, Spindle x x x x
84 481025 Seal, Cutter Spindle x x x x
