Scag Power Equipment SWZ - Manual (Page 18)

19
1 46850 Cutter Deck (Includes decals)
2 46631 CutterSpindle Assembly
3 43296 Spacer, Inside
4 48307-08 Tapered Nut, 5/16-24
5 481022 Tapered Bearing (two)
6 43294 Spindle Housing, Tapered Bearing
7 48114-04 Grease Fitting Str. 5/16
8 43298 Spindle Shaft
9 04001-77 Hex Head Bolt, 3/8-16 x 3-1/2"
10 04063-08 Key, 1/4 x 2"
11 43278 Spacer, Cutter Blade
12 04001-10 Hex Head Bolt, 5/16-18 x 1-1/4"
13 43077 Spacer
14 04019-03 Nut, 5/16-18 Serrated Flange
15 48108 Cutter Blade, 18"
15A 48185 Cutter Blade, 18" High Lift
16 04040-10 Flat Washer, 5/8" W
17 04001-41 Hex Hd. Bolt, 5/8-11 x 9-1/2"
18 46079 Caster Assembly (includes 19-28)
19 04066-01 Quick Pin
20 43037-01 Spacer, Caster Yoke, 1/2" thick
21 48100-01 Bronze Bearing
22 481050 Spring, Chute Return
23 46082 Support Assy. (incl. 21-23)
24 45006 Caster Yoke
25 43022 Sleeve, Caster Wheel Bearing
26 04001-37 Hex Hd. Bolt, 1/2-13 x 5-1/2"
27 04021-07 Hex Locknut, 1/2-13
28 48307 Wheel Assy. (incl. 4,29-34)
29 48307-02 Tire only, Caster Wheel
NS 48006-03 Inner Tube Only (not shown)
30 48307-04 Rim Pair, Caster Wheel
31 48006-07 Retainer, Bearing, Caster Wheel
32 48006-06 Roller Bearing, Caster Wheel
33 48114-03 Grease Fitting 45 deg., 1/4-28
34 48006-05 Hub Assy. (incl. bolts)
35 04017-16 Capscrew, 5/16-18 x 3/4" Serr. Flange Hex Head
36 46725 Discharge Chute
37 04021-10 Hex Nut, 5/16-18 Elastic Stop
38 04001-09 Hex Head Bolt, 5/16-18 x 1"
39 46797 Belt Cover Assembly
Ref. Part
No. No.
Description
Ref. Part
No. No.
Description
36" CUTTER DECK
40 04041-07 Flat Washer, 3/8" (.391 x .938 x .105)
41 04029-03 Wing Nut, 3/8-16
42 48924 Pulley
43 48926 Tapered Hub, 1.125 Bore
44 04001-01 Hex Head Bolt, 1/4-20 x 3/4"
45 04020-09 Hex Nut, 5/8-11
46 48204 Belt, Blade Drive
47 48269 Pulley, Belt Guide
48 04021-05 Nut, Center Locknut - 3/8-16
49 04019-04 Nut, 3/8-16 Serrated Flange
50 04004-02 Support, Belt Cover
51 04017-42 Capscrew, 7/16-14 x 1" Serr. Flange
52 04019-05 Hex Nut, 7/16-14 Serrated Flange
53 43277 Spacer, J-Hook
54 04041-07 Flat Washer
55 04021-09 Nut, 3/8-16 Elastic Stop
56 45423 Idler Pivot
57 46748 Idler Arm Assy. (incl. 22 & 58)
58 48100-02 Bushing, 1-1/8 x 1.0 Flanged
59 04050-05 Retaining Ring, 1-1/8" Ext. "E"
60 44078 J-Hook
61 481025 Seal, Cutter Spindle
62 481024 Seal, Cutter Spindle
63 43297 Spindle Bushing
64 43312 Spacer, Outside
65 48677 Relief Fitting, Cutter Spindle
66 481035 Nut,
67 04041-12 Flat Washer
68 04001-108 Hex Head Bolt, 5/16-18 x 1-1/4"
69 48098 Shield, Spindle
* Common hardware which should be purchased locally. All bolts Grade 5 plated, all other fasteners zinc plated.
