28 GB
5: Connecting the antennas
Connect the supplied AM loop antenna and
FM wire antenna.
Before connecting the antennas, be sure to
disconnect the AC power cord.
*The shape of the connector varies depending on the
area code of this receiver.
Notes
• To prevent noise pickup, keep the AM loop
antenna away from the receiver and other
components.
• Be sure to fully extend the FM wire antenna.
• After connecting the FM wire antenna, keep it as
horizontal as possible.
Y
P B /
C B
P R /
C R
L
R
SAT
IN
BD
IN
OPTICAL
COAXIAL
DIGITAL
DC5V
0.7A MAX
DMPORT
AUDIO
IN
AUDIO
OUT
AUDIO
IN
SA-CD/CD/CD-R TV
SAT IN DVD IN BD IN MONITOR
OUT
COMPONENT VIDEO
ANTENNA
VIDEO
IN
VIDEO
IN
VIDEO
IN
VIDEO
OUT
VIDEO
OUT
AUDIO
OUT
AUDIO
OUT
AUDIO
IN
AUDIO
IN
AUDIO
IN
SAT DVD VIDEO 1 SUBWOOFER
MONITOR
AM
SURROUND BACK SURROUND CENTER
L R
FRONT
L
R
SPEAKERS
FRONT: ONLY FOR SS-MSP7500
CENTER: ONLY FOR SS-CNP7500
SURROUND: ONLY FOR SS-SRP7500 OUT
DC5V
50mA MAX
SYSTEM CONTROL
ONLY FOR TA-KMSW500
DVD
IN
HDMI
DVD IN BD IN OUT
CONNECT TO
DIGITAL
INPUT
FOR AUDIO
FM wire antenna (supplied)
AM loop antenna (supplied)
