Parts Identification
#8-32 x 1-1/8"
Screw
Fixed
Glass
Panel
#10-16
x 3/8"
Screw
#8-18 x
1-1/2"
Screw
1/4" Hex Nut
7/8" Hex
Bolt
#8-18 x 1-1/2" Screw
#8-18 x 3/8" Screw
#8-18 x 3/8" Screw
Top Pivot Bushing
Plastic Bumper Plug
U-Channel
1-1/4" Hex Bolt
Lock Nut
1/4" Hex Nut
Pivot
Jamb
Plastic
Anchor
Plastic
Anchor
Expander
Jamb
Strike
Jamb
Door Panel
Top Track
Pivot Block
Plastic
Plug
Bottom
Pivot
Bushing
Hollow Gasket
Bottom Track
Sterling
3
1034026-2-D
