3 BH69-40321A P/M PACKING-PAD SW-4,W2155*L140,-,DEC,-,-,-,-, SNA
3 BN68-00129A P/M LABEL SHIPPING -,LABEL SHIPPING,ART-PAPER,100G,-,WHT,BLACK,-,-,- SNA
3 BN69-00123L P/M PAD PACKING RJ15PO SNA
3 BN69-00140T P/M PAD-PALLET COVER SUN(LSA810),SW,900,3760,-,-,-,-,- SNA
3 BN69-00617K P/M PALLET-PACKING TS17AS,WOODEN,1310,910,120 SNA
3 BN69-00741A P/M CUSHION-PIVOT MJ17AS,EPS M50 SNA
2 BN92-01052V - ASSY ACCESSORY MJ17/19,ADC,UNITED STATES,PIVOT SNA
3 BN96-01192V UNIT/ACCESSORY ASSY ACCESSORY MJ17/19,ADC,UNITED STATES,PIVOT SNA
4 0203-000214 ACCESSORY TAPE-OPP MASKING OPP/W50/CLR,T0.05,W50,L400000, SNA
4 3903-000085 ACCESSORY CBF-POWER CORD DT,US,BP3/YES,I(IEC C13/C14),125/125V,10/10A,BLK,1830MM,-,SVT AWG18X3,UL/CSA,-,- SA
4 6902-000110 ACCESSORY BAG PE LDPE,T0.05,L356,W240,TRP,28,2,PE MARK SNA
4 AA68-40065B ACCESSORY CARD-01,REGISTRATION ,SEA,A5,ENG,A/P220,2P(SIDES),4 SNA
4 BH68-00261F ACCESSORY CARD WARRANTY-03 SyncMaster14-1,ADC,MOJO180G,E/F,USA SNA
4 BH68-00261R ACCESSORY MANUAL-00 3 MONTHS CRM CARD,SECA,E/F,CANADA,MOJO120G,173,234 SNA
4 BH68-00344C ACCESSORY CARD WARRANTY-00 SECA W’TY & CRM CARD,SECA,MOJO100G,E/F,CANADA SNA
4 BN59-00048A ACCESSORY S/W DRIVER-7.5 SYNCMASTER,PIVOT,SAMSUNG SNA
4 BN96-01171A ACCESSORY ASSY MANUAL P-IB+QSG 710N,SyncMaster,W/W,27Lang,BN59-420A+BH68-376L SNA
5 BH68-00376L CIS MANUAL-01 LCDQUICK SETUP GUIDE,SYNCMASTER,E/F/S/G/P/I..13LANGS,W/W,MOJO100G,298,420 SA
5 BN59-00420A CIS S/W DRIVER-00,IB 710T,W/W,SyncMaster,27 Lang SNA
2 BN92-01057Y - ASSY BOX MJ17ASAB,ADC,UNITED STATES,S/M711N,POIVOT,TCO99 SNA
3 BH68-00530E BOX LABEL BOX-01 ALL MODEL,MOJO 90G,90,95,WHT,3Y W/T+TCO99+PIVOT SNA
3 BN69-00806E BOX BOX-00 S/M711N(MJ17AS) W/W,CB-SW4,YEL,A-1,L496*W395*H214,PIVOT SNA
1 E29-MJ17ASAB - 2 SEC,LTM170EU-L11 ZPD -
7 Electrical Parts List
7-8 MJ15AS*/MJ17AS*/MJ19AS*/
MJ15BS*/MJ17BS*/MJ19BS*
Level Loc. No. Code No. Description Specification Remarks
0 MJ19ASAB/XSH
1 E10-MJ19ASAB/XSH - 1 LTM190E1-L02 -
3 BN94-00516T - ASSY PCB MAIN-E10/E17 GS19VS/MJ19AS SNA
4 0204-002420 CIS3 SOLVENT 1M-1000,C3H70H,96,-,- SNA
4 0204-002426 CIS4 FLUX DF-201TVS,MIX,0.820,FLUX13%,14KG,- SNA
4 BN63-00995A CIS8 GASKET GY17MS,CONDUCTIVE FAB,4MM,15MM,100MM,GRAY,32K,71TSSK-15-4-100-13 SNA
4 3701-001219 CN101 CONNECTOR-DSUB 15P,3R,FEMALE,ANGLE,AUF SA
4 3711-004712 CN600 CONNECTOR-HEADER BOX,9P,1R,2mm,STRAIGHT,SN SA
4 6003-000117 IP/PCB+BRKT/PCB SCREW-TAPTITE BH,+,B,M3,L6,ZPC(YEL),SWRCH18A SNA
4 6003-000117 M/PCB+BRKT/PCB SCREW-TAPTITE BH,+,B,M3,L6,ZPC(YEL),SWRCH18A SNA
4 BN97-00354K MICOM ASSY MICOM GS17VS SA
5 0903-001347 IC200 IC-MICROCONTROLLER NT68F63GL,8Bit,PLCC,44P,653MIL,12MHz,ST,-,PLASTIC,5.000000V,-,-0to+70C,256B,-,-, SNA
5 BN82-00114L CIS A/S MICOM GS17VS SNA
4 BN97-00358G - ASSY SMD GS17VS/17VT/GS19VT SNA
5 3301-000314 BD100 BEAD-SMD 120ohm,1.6x0.8x0.8mm,150mA,,,,40000ohm SNA
5 3301-000314 BD101 BEAD-SMD 120ohm,1.6x0.8x0.8mm,150mA,,,,40000ohm SNA
5 3301-000314 BD102 BEAD-SMD 120ohm,1.6x0.8x0.8mm,150mA,,,,40000ohm SNA
5 3301-000314 BD103 BEAD-SMD 120ohm,1.6x0.8x0.8mm,150mA,,,,40000ohm SNA
5 3301-000314 BD104 BEAD-SMD 120ohm,1.6x0.8x0.8mm,150mA,,,,40000ohm SNA
5 3301-000314 BD105 BEAD-SMD 120ohm,1.6x0.8x0.8mm,150mA,,,,40000ohm SNA
5 2703-001334 BD106 INDUCTOR-SMD 1.5uH,10%,2012 SA
5 3301-000314 BD200 BEAD-SMD 120ohm,1.6x0.8x0.8mm,150mA,,,,40000ohm SNA
5 3301-000314 BD201 BEAD-SMD 120ohm,1.6x0.8x0.8mm,150mA,,,,40000ohm SNA
5 2203-005005 C100 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C101 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C102 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C103 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C104 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C105 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-000257 C106 C-CER,CHIP 10nF,10%,50V,X7R,TP,1608 SA
5 2203-005005 C110 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C112 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
Level Loc. No. Code No. Description Specification Remarks
7-3-1 MJ19AS* Main PCB Parts
