5 2203-005005 C423 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C424 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005065 C603 C-CER,CHIP 1000nF,+80-20%,10V,Y5V,-,1608 SA
5 2203-005005 C604 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C605 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005065 C606 C-CER,CHIP 1000nF,+80-20%,10V,Y5V,-,1608 SA
5 2402-001042 C607 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm SA
5 2203-005005 C608 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2402-001042 C609 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm SA
5 2203-005005 C610 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2402-001042 C611 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm SA
5 2402-001042 C612 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm SA
5 3711-005543 CN200 CONNECTOR-HEADER BOX,6P,1R,1.25mm,SMD-A,SnPb,IVR SA
5 3711-005470 CN400 CONNECTOR-HEADER BOX,30P,1R,1.25mm,SMD-A,Sn+Pb,IVR SA
5 0403-001411 D100 DIODE-ZENER -,5.49-5.73V,200MW,SOD-323,TP SA
5 0401-001056 D101 DIODE-SWITCHING MMBD4148SE,100V,200MA,SOT-23,TP SA
5 0401-001056 D103 DIODE-SWITCHING MMBD4148SE,100V,200MA,SOT-23,TP SA
5 0401-001056 D105 DIODE-SWITCHING MMBD4148SE,100V,200MA,SOT-23,TP SA
5 0402-001080 D600 DIODE-RECTIFIER GF1G,400V,1A,DO,TP SA
5 0406-001061 IC106 DIODE-TVS MMQA5V6T3,5.32/5.6/5.88V,24W,S SA
5 1103-001023 IC201 IC-EEPROM 24C08,1Kx8,SOP,8P,5x4mm,2.5/5.5V,0to+70C SA
5 1003-001674 IC400 IC-LCD CONTROLLER SE7889,PQFP,100P,23.45x17.45mm,-,-,TR,PLASTIC,0.3-3.6V,0to+70C,-,-,- SNA
5 0505-001772 IC600 FET-SILICON FDS9933A,P,-20V,-3.8A,0.075OHM,2W,SO-8 SA
5 1203-003209 IC601 IC-DUAL VOLTAGE REGULATOR APL5522,SOP,8P,4.9x3.9mm,PLASTIC,3.3V/2.5V,-,0to+150C,500mA/300mA,-,TP SA
5 1203-001293 IC602 IC-POSI.FIXED REG. 033,T0-252,3P,6.5MIL,PLASTIC,3 SA
5 BN41-00412A MP1.0 PCB MAIN MJ/GS,SILVER THROGH HOLE,2L,1.0,1.6T,118*78.2,4A SNA
5 0501-002080 Q601 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SC-59,TP,120-270 SA
5 2007-000821 R106 R-CHIP 390ohm,1%,1/10W,TP,1608 SA
5 2007-001164 R107 R-CHIP 75ohm,1%,1/10W,TP,1608 SA
5 2007-001164 R108 R-CHIP 75ohm,1%,1/10W,TP,1608 SA
5 2007-001164 R109 R-CHIP 75ohm,1%,1/10W,TP,1608 SA
5 2007-001164 R118 R-CHIP 75ohm,1%,1/10W,TP,1608 SA
5 2703-001334 R119 INDUCTOR-SMD 1.5uH,10%,2012 SA
5 2007-001164 R120 R-CHIP 75ohm,1%,1/10W,TP,1608 SA
5 2703-001334 R121 INDUCTOR-SMD 1.5uH,10%,2012 SA
5 2007-000084 R122 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 SA
5 2007-000090 R123 R-CHIP 10Kohm,5%,1/10W,TP,1608 SA
5 2007-000078 R124 R-CHIP 1Kohm,5%,1/10W,TP,1608 SA
5 2007-000113 R134 R-CHIP 33ohm,5%,1/10W,TP,1608 SA
5 2007-000113 R135 R-CHIP 33ohm,5%,1/10W,TP,1608 SA
5 2007-000113 R136 R-CHIP 33ohm,5%,1/10W,TP,1608 SA
5 2007-000113 R137 R-CHIP 33ohm,5%,1/10W,TP,1608 SA
5 2007-000113 R138 R-CHIP 33ohm,5%,1/10W,TP,1608 SA
5 2007-000113 R139 R-CHIP 33ohm,5%,1/10W,TP,1608 SA
5 2007-000070 R200 R-CHIP 0ohm,5%,1/10W,TP,1608 SA
5 2007-000090 R202 R-CHIP 10Kohm,5%,1/10W,TP,1608 SA
5 2007-000090 R203 R-CHIP 10Kohm,5%,1/10W,TP,1608 SA
5 2007-000084 R204 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 SA
5 2007-000084 R205 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 SA
5 2007-000084 R206 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 SA
5 2007-000084 R207 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 SA
5 2007-000084 R208 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 SA
5 2007-000084 R209 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 SA
5 2007-000084 R210 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 SA
5 2007-000084 R211 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 SA
5 2007-000084 R212 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 SA
5 2007-000090 R214 R-CHIP 10Kohm,5%,1/10W,TP,1608 SA
5 2007-000084 R216 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 SA
5 2007-000084 R217 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 SA
5 2007-000084 R219 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 SA
5 2007-000077 R221 R-CHIP 470ohm,5%,1/10W,TP,1608 SA
5 2007-000080 R222 R-CHIP 2Kohm,5%,1/10W,TP,1608 SA
5 2007-000074 R223 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000074 R224 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000074 R225 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000074 R226 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000070 R227 R-CHIP 0ohm,5%,1/10W,TP,1608 SA
5 2007-000074 R228 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000074 R229 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000074 R230 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000074 R231 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000074 R232 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000083 R233 R-CHIP 3Kohm,5%,1/10W,TP,1608 SA
5 2007-000074 R234 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000074 R235 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000074 R236 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
7 Electrical Parts List
7-2 MJ15AS*/MJ17AS*/MJ19AS*/
MJ15BS*/MJ17BS*/MJ19BS*
Level Loc. No. CodeNo. Description Specification Remarks
